ELAC SUB 2060 D
ELAC SUB 2080 D
ELAC SUB 211 D
Bedienungsanleitung
Operating Instructions
Wir beglückwünschen Sie zum Kauf des ELAC SUB 2060 / 2080 / 211 D, der unter
strengen Qualitäts- und Umweltauflagen hergestellt wurde. Um die Leistung voll auszu-
nutzen, lesen Sie bitte die Bedienungsanleitung gründlich durch. Wir raten Ihnen, diese
Anleitung für späteres Nachschlagen gut aufzubewahren.
Bitte beachten Sie die separaten Sicherheitshinweise, die der Verpackung Ihres
neuen Subwoofers beigepackt sind. Bitte lesen, beachten und befolgen Sie alle diese
Sicherheitshinweise und bewahren Sie diese ebenfalls auf. Beachten Sie alle Warnun-
gen, die auf dem Gerät und in der Bedienungsanleitung aufgeführt sind.
Congratulations on the purchase of your ELAC SUB 2060 / 2080 / 211 D that has been
designed in accordance with strict quality and environmental requirements.
Please read the instruction manual carefully.
We recommend keeping it in a safe place for future reference. Please note the en-
closed safety instructions. Please follow the instructions and keep the safety instruc-
tions. Heed all warnings on the appliance and in the manual.

Table of Contents

Questions and Answers

  • H
    Heather CarterAug 13, 2025
    What to do if my ELAC SUB 2060 D Subwoofer has no signal?
    • R
      Richard CamachoAug 13, 2025
      If your ELAC Subwoofer has no signal, several issues could be the cause. First, check or replace the mains fuse. Then, check the mains switch, plugs, and socket to ensure there's a proper connection. Make sure the power mode switch is in the AUTO or ON position. Finally, inspect the input connections, exchange the RCA connector, and verify the source signal by testing if a different audio component fed by the same source is playing correctly.
  • L
    linda57Aug 16, 2025
    Why is my ELAC SUB 2060 D's max output slightly too low?
    • R
      Rebecca NunezAug 16, 2025
      If the max output of your ELAC Subwoofer is slightly too low, it might be due to its placement. Try placing the subwoofer in front of a wall or in a corner to improve the output.
  • V
    victoriadavisAug 20, 2025
    Why is my ELAC SUB 2060 D making a loud hum?
    • C
      chadwillisAug 20, 2025
      If your ELAC Subwoofer is emitting a loud hum, it could be due to contact problems with the RCA connector or adapter. Check all connections and reduce the level on the ELAC sub to -30dB. You may also need to readjust the outer rings of the RCA plugs.
  • A
    Amanda MooreAug 25, 2025
    What to do if my ELAC SUB 2060 D Subwoofer has an uneven sound?
    • S
      Sandra JacksonAug 25, 2025
      If your ELAC Subwoofer has an uneven sound, the polarity might be unfavorable. Try switching the polarity. If there's no signal difference, move the subwoofer by 0.5 – 2 meters and repeat the process.
  • M
    Melissa BrownAug 27, 2025
    What to do if my ELAC Subwoofer output level is too low (RCA jack)?
    • A
      April JonesAug 27, 2025
      If the output level from your ELAC Subwoofer's RCA jack is too low, the output level from the source (pre-amp, surround decoder) might be too low. Increase the output level of the pre-amp to a minimum of 0.2 Volts, then reduce the power amp for compensation. Alternatively, slightly reduce the level of the main (center, effect) speakers and increase the master volume for compensation.
  • C
    Christine AndersonSep 1, 2025
    How to fix a soft hum during pauses in my ELAC SUB 2060 D Subwoofer?
    • K
      Katie JenningsSep 1, 2025
      To check your ELAC sub for inherent hum, switch the MODE to OFF, disconnect all inputs, then switch to ON with normal settings. With your ear near the speaker, there may be a soft hum, but there should be none at the listening place. The hum might be caused by a ground loop with RCA multi-connections.
  • J
    James GomezSep 4, 2025
    What to do if my ELAC SUB 2060 D Subwoofer output level is too low (speaker cable)?
    • L
      Lee FlemingSep 4, 2025
      If the output level of your ELAC Subwoofer is too low when using a speaker cable, one channel might be inverted. Try disconnecting one channel; if the bass level is now higher, reconnect the second channel with inverted polarity. Also, check the cables for any polarity errors.
  • J
    Jesse MoodySep 8, 2025
    Why is my ELAC SUB 2060 D sound somewhat distorted during loud tracks?
    • B
      Brittany WardSep 8, 2025
      If the sound from your ELAC Subwoofer is somewhat distorted during loud tracks, especially in surround mode with loud buzzing noises, it could be due to overdrive of the center or effect speakers and their power amps. Reduce the center or effect level at the surround decoder and use the center mode ‘normal’.

Summary

Control and Connection Elements Overview

Control Panel Operation

Volume Adjustment

Sets the sound volume of the subwoofer in conjunction with other speakers.

Crossover Frequency Setting

Sets the upper boundary frequency for subwoofer sound reproduction.

Operating Mode Selection

Selects operating mode: AUTO (stand-by) or ON (permanent).

EQ 1 Equalizer Configuration

Adjusts room resonance and frequency response for sound tuning.

EQ 2 Room Resonance Filter

Specifically suppresses room resonances and unwanted peaks.

Subwoofer Connectivity

Digital Surround: LFE;Mono In (Unbalanced)

Home Cinema: Line Level Input

Digital Surround: Balanced LFE;Mono In

Home Cinema: Bass Management

Hi-Fi;Stereo: Bass Support

Hi-Fi Stereo: Balanced Input (SUB 2080 D)

Troubleshooting Guide

ELAC SUB 2060 D Specifications

General IconGeneral
TypeActive Subwoofer
Driver Size12-inch
Amplifier TypeClass D
Auto On/OffYes
Weight30 kg
InputsRCA
OutputsRCA
Crossover Frequency50Hz - 150Hz
Phase Adjustment0° to 180°
