Outrigger Feet & Spike Installation (UF52 Only)
Using the included feet provide a wider support base for speaker cabinet. The included spikes improve stability
on uneven surfaces and thickly carpeted floors. Please, use caution when dealing with spikes as they are sharp.
IMPORTANT! In order to prevent scratching or damage the cabinet, turn the speaker upside down onto a soft
surface while you attach the outrigger feet and spikes. We highly recommend a second person help with this
process.
A. Attach the feet with provided machine screws (see fig.A).
B. Screw in the spikes as shown in FIG.B. The speaker can now be
turn back over. Please, be careful when handling the speaker with
the spikes installed. If you have hard wood tile floors, please use the
provided floor discs (fig.B).
C. Using the supplied allen wrench adjust the height of the spikes
until the speaker sits level and all four spikes are touching the floor
(fig.C).
D. Once the speaker is level, use the supplied covers to lock the
spikes into place (fig.D).
FIG.A
FIG.B
FIG.C
FIG.D
ELAC Uni-Fi 2.0 Speakers | www.elac.com | Page 4
