Owner's Manual
4.2.2
230 V
unpolarised
2
1
1
•
•
•
•
•
To avoid a power spike, turn OFF all main breakers before plugging IN
the shore power cord. Securely connect the power inlet of the boat and
the shore power receptacle. If the connection is broken and later re-
secured, the main breaker will trip. Connections must be secure for
uninterrupted dock-side service.
Caution
The RCD (residual current device) should be tested monthly by pressing
the “TEST” button. The RCD should trip “OFF” immediately. Reset the
RCD by flicking the switch back to “ON”. If the RCD does not trip “OFF”
immediately, there is a fault: disconnect all AC power sources and call a
qualified electrician to investigate.
Generator Optional - aft of engine
The main switch board location:
To minimise shock and fire hazards:
Location
Inverter
The system is:
Source of power
Shore connection
The AC system consists of the following sources of power:
Transom - below helm seat
The alternating current (AC) system is supplied with power by the sources listed below. These supply
the components listed in tables below which show the settings of the overload protection
breakers/fuses.
AC System
The power source selector switch is located on the AC panel board.
Above navigation station in port aft corner of saloon
Disconnect shore-power cable at shore-power source first.
Turn off craft's shore-power connection switch before
connecting or disconnecting shore-power cable.
Do not allow the shore-power cable end to hang in the water. An electrical
field can be caused which can cause injury or death to nearby swimmers.
Warning
Danger
Connect shore-power cable to craft's inlet before connecting
to shore power source.
Use double insulated or grounded (earthed) electrical appliances.
Information
Caution
Caution
Connect metallic housings or enclosures of installed electrical appliances
to the protective conductor system in the craft (green or green with yellow
stripe conductor).
Close shore-power inlet cover tightly.
Do not alter shore-power cable connectors & use only
compatible connectors.
Optional - below stbd aft berth
Technical Software
© Licensed User: Elan d.o.o., 2019
14/44
