Elan Impression i40.1 - Thrusters; Anchor Windlass

Owner's Manual
2. Layout option 2 cabins
4.7
4.8
•
•
•
Ensure the joysticks are in neutral to prevent the thrusters from running
when not required.
Caution
These units are controlled by joystick from the steering position.
The craft is fitted with thrusters as follows:
Anchor Windlass
Warning
Information
have experienced crew operate the windlass
The windlass can be operated by local controls at the unit or by remote
control from either steering position.
Thrusters
Electric
The craft is fitted with a powered anchor windlass on the foredeck.
Winches and windlasses generate large forces by the push of a button.
Always:
prevent accidental pressing of switches
keep hands and feet away from the windlass
Stern
Power Source
Not fitted
Thruster
Bow
01
Galley sink outlet
0
9
D
ockside deck discharge gland
02
Galley sink gray water seacock
10
FWD toilet sink outlet
03
Sea water inlet seacock
11
FWD toilet sink gray water seacock
04 Toilet sink outlet 12 FWD toilet flush water seacock
05
Toilet sink gray water
seacock
13
Macerator pump
06
To
ilet flush water seacock
14
Macerator pump outlet seacock
07
Black water holding tank
15
Manual
to
ilet
08
Holding tank airvent
16
FWD manual
toilet
