I N S T A L L A T I O N G U I D E L I N E S
POWER AND DATA CABLES
TO MAINTAIN THE IP65 RATING INTEGRITY OF THE FIXTURE, ALL CABLES MUST BE
RUN TOWARDS THE GROUND TO PREVENT WATER ACCUMULATION AROUND THE
CONNECTIONS.
ART-NET | sACN CONNECTION
When connecting xture to a network switch to control multiple devices, a Gigabit Ethernet
Switch that supports IGMP (Internet Group Management Protocol) is required. Using a
Gigabit Ethernet Switch that does not support IGMP can cause erratic behavior of all
connected devices to the switch. Click link below for more information about IGMP.
https://en.wikipedia.org/wiki/Internet_Group_Management_Protocol
SYSTEM MENU LCD DISPLAY
CABLES CABLES
INCLUDED RJ45 DATA CABLE
THE INCLUDED RJ45 DATA CABLE IS FOR FIXTURE TO FIXTURE INTERCONNECTION
ONLY! THE RJ45 CABLE CONNECTORS MAY NOT BE COMPATIBLE WITH OTHER
RJ45/ETHERCON TYPE CONNECTORS.
