Elation Proteus Lucius - Fixture Overview

9
Lens
Tilt Lock
LEFT Button
ENTER Button
RIGHT Button
UP Button
MODE/ESC
Button
DOWN Button
LCD Menu Function Display
Carrying Handle(s)
PAN Lock
5pin DMX Input
5pin DMX Output
RJ45 Output
Valve
Locking Power Input
RJ45 Input
Safety Cable
Attachment Point
ALWAYS ATTACH A SAFETY CABLE
WHENEVER INSTALLING THIS DEVICE
IN A SUSPENDED ENVIRONMENT TO
ENSURE THE FIXTURE WILL NOT
DROP IF THE CLAMP FAILS.
