Elation Proteus Lucius - DMX Channel Functions and Values

3 1
ELATION PROTEUS LUCIUS
DMX Channel Values / Functions
Supports Software Versions: ≥ 1.3.0
Features subject to change without notice
MODE/CHANNEL
VALUE FUNCTION
HOLD
TIME
DEFAULT SNAP
Standard Extended
1 1
PAN Movement 8bit:
127
0-255 Pan Movement
2 2
Pan Fine 16bit:
127
0-255 Fine control of Pan movement
3 3
TILT Movement 8bit:
127
0-255 Tilt Movement
4 4
Tilt Fine 16bit:
127
0-255 Fine control of Tilt movement
5 5
Cyan:
0-255 Cyan (0-100% Cyan)
6
Cyan Fine:
0-255 Cyan Fine
6 7
Magenta:
0-255 Magenta (0-100% Magenta)
8
Magenta Fine:
0-255 Magenta Fine
7 9
Yellow:
0-255 Yellow (0-100% Yellow)
10
Yellow Fine:
0-255 Yellow Fine
8 11
CTO:
0-255 CTO (0-100% CTO)
12
CTO Fine:
0-255 CTO Fine
9 13
Color Wheel:
X
0-7 Open
8-31 Red
32-55 Green
56-79 High CRI
80-103 Orange
104-127 Medium Blue
128-189 Clockwise eect from fast to slow
190-193 No rotation
194-255 Counter-clockwise eect from slow to fast
14
Color Wheel Fine:
X
0-255 Fine Control of Color Wheel position
DMX TRAITS: CHANNEL FUNCTIONS & VALUES
