Elation Proteus Lucius - Page 44

4 4
D I M E N S I O N S
*Drawings not to scale. Specications and improvements in the design of this unit and this manual are subject to change without notice.
B
B
AA
22.4in. [570mm]
21.3in. [540mm]
18.9in. [504.3mm]
14.1in. [357.7mm]
14.3in. 364.4mm]
16.5in. [418mm]
17.5in. [444.6mm]
22.5in. [572mm]
2.4in. [61mm]
3.7in. [93mm]
18in. [457mm]
A-A
B-B
5in.
[127mm]
4.7in.
[120mm]
1.8in.
[45mm]
6.9in.
[175mm]
5.7in.
[145mm]
1.8in.
[45mm]
1.0in.
[25mm]
3.9in.
[100mm]
4.9in.
[125mm]
3°
5.4in.
[137.4mm]
18.0in. [457mm]
18.1in. [460mm]
21.4in. [544mm]
