elco Combi 24 User Manual

31
Parameters end users
Menu Line no. Selection possibilities Unit Min. Max Factory
setting
Time program 5 600 Preselection - Mo-Su, Mo-Fr, Sa-Su Mo-Su, Mo-Fr, Sa-Su Mo-Su
601 Mo-Su: 1. Phase On uu:mm 00:00 24:00 06:00
602 Mo-Su:1.PhaseO󰀨 uu:mm 00:00 24:00 22:00
603 Mo-Su: 2. Phase On uu:mm 00:00 24:00 --.--
604 Mo-Su:2.PhaseO󰀨 uu:mm 00:00 24:00 --.--
605 Mo-Su: 3. Phase On uu:mm 00:00 24:00 --.--
606 Mo-Su:3.PhaseO󰀨 uu:mm 00:00 24:00 --.--
616 Default values - Yes No No
Holidays HC1 641 Preselection - Period 1, 2, 3, 4, 5, 6, 7, 8 Period 1
642 Period Start Day / Month tt.MM 01.01 31.12 --.--
643 Periode End Day / Month tt.MM 01.01 31.12 --.--
648 Operating level - Frost protection, Reduced Frost protection Frost protection
Holidays HC2
(When activated)
651 Preselection - Period 1, 2, 3, 4, 5, 6, 7, 8 Period 1
652 Period Start Day / Month tt.MM 01.01 31.12 --.--
653 Periode End Day / Month tt.MM 01.01 31.12 --.--
658 Operating level - Frost protection, Reduced Frost protection Frost protection
HC1 710 Comfort setpoint °C Value from Line no. 712 35 20.0
712 Reduced setpoint °C 4 Value from Line no. 710 16.0
714 Frost protection setpoint °C 4 Value from Line no. 712 10.0
720 Heating curve slope - 0.10 4.00 1.50
730 Summer/winter heating limit °C ---/8 30 20
HC 2
(When activated)
1010 Comfort setpoint °C Value from Line no. 1012 35 20.0
1012 Reduced setpoint °C 4 Value from Line no. 1010 16.0
1014 Frost protection setpoint °C 4 Value from Line no. 1012 10.0
1020 Heating curve slope - 0.10 4.00 0.8
1030 Summer/winter heating limit °C ---/8 30 0
DHW 1600 Operating mode - O󰀨,On,Eco O󰀨
1610 Nominal setpoint °C Value from Line no. 1612 80 55
1612 Reduced setpoint °C 8 Value from Line no. 1610 40
Swimming pool 2055 Pool setpoint solar heating °C 8 80 26
2056 Pool sepoint boiler heating °C 8 80 22
Boiler 2214 Setpoint manual control °C 10 90 50
Error 6700 Error message - - - Indication only
6705 SW Diagnose Code - - - Indication only
6706 Burner ctrl phase lockout pos - - - Indication only
