Parameters technician
Menu Line no. Selection possibilities Unit Min. Max Factory setting
Boiler 2210 Setpoint min °C 8 95 20
2212 Setpoint max °C 8 120 85
2214 Setpoint manual control °C 8 120 50
2233 P-Band Xp HCs °C 1 200 64
2234 Int action time Tn HCs s 4 873 75
2235 Der action time Tv HCs s 0 30 0
2236 P-Band Xp DHW °C 1 200 21
2237 Int action time Tn DHW s 4 873 75
2238 Der action time Tv DHW s 0 30 0
2241 Burner running time min min 0 20 0
2243 Burnero󰀨timemin min 0 60 15
2245 SDburnero󰀨time °C 0 80 15
2250 Pump overrun time min 0 240 3
2253 Pump overr time after DHW min 0 20 1
2270 Return setpoint min °C 8 95 8
2301 Boiler pump on heat gen lock - O󰀨,On O󰀨
2305 Impact heat generation lock - Heating mode only, Heating and DHW
mode
Heating mode only
2316 Tempdi󰀨erentialmax °C 0 80 25
2317 Tempdi󰀨erentialnominal °C 0 80 20
2320 Pump modulation - None, Demand, Boiler setpoint,
Tempdi󰀨erentialnominal,Burneroutput
Tempdi󰀨erentialnominal
2321 Starting speed % 0 100 100
2322 Pump speed min % 0 100 45
2323 Pump speed max % 0 100 THI S PLUS 13: 45
THI S PLUS 19: 55
THI S PLUS 24 / Combi 24: 60
THI S PLUS 34 / Combi 34: 75
THI S PLUS 35L: 55
THI S PLUS 46: 70
THI S PLUS 54: 90
2324 Speed Xp °C 1 200 32
2325 Speed Tn s 10 873 120
2326 Speed Tv s 0 30 10
2329 Pump setpoint reduction °C 0 20 10
2330 Output nominal kW 0 2000
THI S PLUS 13: 13
THI S PLUS 19: 19
THI S PLUS 24 / Combi 24: 24
THI S PLUS 34 / Combi 34: 34
THI S PLUS 35L: 35
THI S PLUS 46: 46
THI S PLUS 54: 54
2331 Output basic stage kW 0 2000
THI S PLUS 13: 4
THI S PLUS 19: 4
THI S PLUS 24 / Combi 24: 4
THI S PLUS 34 / Combi 34: 6
THI S PLUS 35L: 9
THI S PLUS 46: 9
THI S PLUS 54: 9
2334 Output at pump speed min % 0 100 0
2335 Output at pump speed max % 0 100 100
2441 Fan speed heating max rpm 0 1000
THI S PLUS 13: 3580
THI S PLUS 19: 4620
THI S PLUS 24: 5450
THI S PLUS Combi 24: 3720
THI S PLUS 34 / Combi 34: 5600
THI S PLUS 35L: 3600
THI S PLUS 46: 4750
THI S PLUS 54: 5400
2442 Fan speed full charging max rpm 0 1000 See Line no. 2441
2444 Fan speed DHW max rpm 0 1000
THI S PLUS 13: 3580
THI S PLUS 19: 4620
THI S PLUS 24: 5450
THI S PLUS Combi 24: 5130
THI S PLUS 34 / Combi 34: 5600
THI S PLUS 35L: 3600
THI S PLUS 46: 4750
THI S PLUS 54: 5400
