elco Combi 24 - Page 39

39
Parameters technician
Menu Line no. Selection possibilities Unit Min. Max Factory setting
Conguration 5700 Presetting - 1 4 1
5710 Heating circuit 1 - O󰀨,On On
5715 Heating circuit 2 - O󰀨,On O󰀨
5721 Heating circuit 3 - O󰀨,On O󰀨
5730 DHW sensor - DHW sensor B3, Thermostat,
DHW outlet sensor B38
DHW sensor B3
5731 DHW controlling element - No charging request, Charging pump,
Diverting valve
Charging pump
5734 Basic pos DHW div valve - Last request, Heating circuit, DHW Last request
5736 DHW separate circuit - O󰀨,On O󰀨
5737 Optg action DHW div valve - Position On DHW, Position On HC Position On DHW
5774 Ctrl boiler pump/DHW valve - All requests, Request HC1/DHW only All requests
5840 Solar controlling element - Charging pump, Diverting valve Charging pump
5841 External solar exchanger - Jointly,DHWstoragetank,Bu󰀨erstoragetank Jointly
5870 Combi storage tank - No, Yes No
5890 Relay output QX1 - 0: None
1:Circulating pump Q4
2:El imm heater DHW K6
3:Collector pump Q5
4:Cons circuit pump VK1 Q15
5:Boiler pump Q1
6:Bypass pump Q12
7:Alarm output K10
8:2nd pump speed HC1 Q21
9:2nd pump speed HC2 Q22
10:2nd pump speed HC3 Q23
11:Heat circuit pump HC3 Q20
12:Cons circuit pump VK2 Q18
13:System pump Q14
14:Heatgenshuto󰀨valveY4
15:Solid fuel boiler pump Q10
16:Time program 5 K13
17:Bu󰀨erreturnvalveY15
18:Solar pump ext exch K9
19:Solarctrlelembu󰀨erK8
20:Solar ctrl elem swi pool K18
22: Swimming pool pump Q19
25:Cascade pump Q25
26:St tank transfer pump Q11
27:DHW mixing pump Q35
28:DHW interm circ pump Q33
29:Heat request K27
30:Refrigeration request K28
33:Heat circuit pump HC1 Q2
34:Heat circuit pump HC2 Q6
35:DHW ctrl elem Q3
36:Instant heater ctrl elem Q34
38:WaterllingK34
39:2nd boiler pump speed Q27
40:Status output K35
41:Status information K36
42:Flue gas damper K37
43:Fan shutdown K38
None
5891 Relay output QX2 - None
5892 Relay output QX3 - DHW ctrl elem Q3
5930 Sensor input BX1 - 0: None
1:DHW sensor B31
2:Collector sensor B6
4:DHW circulating sensor B39
5:Bu󰀨ersensorB4
6:Bu󰀨ersensorB41
7:Flue gas temp sensor B8
8:SegmentowsensorB10
9:Solid fuel boiler sensor B22
10:DHW charging sensor B36
11:Bu󰀨ersensorB42
12:Segment return sensor B73
13:Cascade return sensor B70
14:Pool sensor B13
16:SolarowsensorB63
17:Solar return sensor B64
19: Primary exch sensor B26
None
5931 Sensor input BX2 - None
5932 Sensor input BX3 - Flue gas temp sensor
B8
