elco Combi 24 - Page 40

40
Parameters technician
Menu Line no. Selection possibilities Unit Min. Max Factory setting
Conguration 5950 Function input H1 - 0: None
1:Optg mode change HCs+DHW
2:Optg mode changeover DHW
3:Optg mode changeover HCs
4:Optg mode changeover HC1
5:Optg mode changeover HC2
6:Optg mode changeover HC3
7:Heat generation lock
8:Error/alarm message
9:Consumer request VK1
10:Consumer request VK2
11:Release swi pool source heat
12:Excess heat discharge
13:Release swi pool solar
14:Operating level DHW
15:Operating level HC1
16:Operating level HC2
17:Operating level HC3
18:Room thermostat HC1
19:Room thermostat HC2
20:Room thermostat HC3
21:DHWowswitch
22:DHW thermostat 24: Pulse count
28:Checkbsignuegasdamper
29:Start prevention
31:Boilerowswitch
32:Boiler pressure switch
51:Consumer request VK1 10V
52:Consumer request VK2 10V
54: Pressure measurement 10V
58: Preselected output 10V
None
5960 Function input H3 - Consumer request
VK1 10V
5951 Contact type H1 -
NC, NO
NO
5961 Contact type H3 - NO
5953 Voltage value 1 H1 V 0 10 2
5954 Function value 1 H1 - -1000 5000 200
5955 Voltage value 2 H1 V 0 10 10
5956 Function value 2 H1 - -1000 5000 850
5970 Function input H4 - 0: None
1:Optg mode change HCs+DHW
2:Optg mode changeover DHW
3:Optg mode changeover HCs
4:Optg mode changeover HC1
5:Optg mode changeover HC2
6:Optg mode changeover HC3
7:Heat generation lock
8:Error/alarm message
9:Consumer request VK1
10:Consumer request VK2
11:Release swi pool source heat
12:Excess heat discharge
13:Release swi pool solar
14:Operating level DHW
15:Operating level HC1
16:Operating level HC2
17:Operating level HC3
18:Room thermostat HC1
19:Room thermostat HC2
20:Room thermostat HC3
21:DHWowswitch
22:DHW thermostat 24: Pulse count
28:Checkbsignuegasdamper
29:Start prevention
31:Boilerowswitch
32:Boiler pressure switch
50: Flow measurement Hz
None
5971 Contact type H4 - NC, NO NO
5973 Frequency value 1 H4 - 0 1000 0
5974 Function value 1 H4 - -1000 5000 0
5975 Frequency 2 H4 - 0 1000 0
5976 Function value 2 H4 - -1000 0
