elco Combi 24 - Page 41

41
Parameters technician
Menu Line no. Selection possibilities Unit Min. Max Factory setting
Conguration 5977 Function input H5 - 0: None
1:Optg mode change HCs+DHW
2:Optg mode changeover DHW
3:Optg mode changeover HCs
4:Optg mode changeover HC1
5:Optg mode changeover HC2
6:Optg mode changeover HC3
7:Heat generation lock
8:Error/alarm message
9:Consumer request VK1
10:Consumer request VK2
11:Release swi pool source heat
12:Excess heat discharge
13:Release swi pool solar
14:Operating level DHW
15:Operating level HC1
16:Operating level HC2
17:Operating level HC3
18:Room thermostat HC1
19:Room thermostat HC2
20:Room thermostat HC3
21:DHWowswitch
22:DHW thermostat
24: Pulse count
28:Checkbsignuegasdamper
29:Start prevention
31:Boilerowswitch
32:Boiler pressure switch
None
5978 Contact type H5 - NC, NO NC
6020 Function extension module 1 - 0: None
1:Multifunctional
2:Heating circuit 1
3:Heating circuit 2
4:Heating circuit 3
5:Return temp controller
6:Solar DHW
7:Primary contr/system pump
No function
6021 Function extension module 2 - No function
6022 Function extension module 3 - No function
6024 Funct input EX21 module 1 - 0: None
25: Limit thermostat HC
None
6026 Funct input EX21 module 2 - None
6028 Funct input EX21 module 3 - None
6030 Relay output QX21 module 1 - 0: None
1:Circulating pump Q4
2:El imm heater DHW K6
3:Collector pump Q5
4:Cons circuit pump VK1 Q15
5:Boiler pump Q1
6:Bypass pump Q12
7:Alarm output K10
8:2nd pump speed HC1 Q21
9:2nd pump speed HC2 Q22
10:2nd pump speed HC3 Q23
11:Heat circuit pump HC3 Q20
12:Cons circuit pump VK2 Q18
13:System pump Q14
14:Heatgenshuto󰀨valveY4
15:Solid fuel boiler pump Q10
16:Time program 5 K13
17:Bu󰀨erreturnvalveY15
18:Solar pump ext exch K9
19:Solarctrlelembu󰀨erK8
20: Solar ctrl elem swi pool K18
22: Swimming pool pump Q19
25:Cascade pump Q25
26:St tank transfer pump Q11
27:DHW mixing pump Q35
28:DHW interm circ pump Q33
29:Heat request K27
30:Refrigeration request K28
33:Heat circuit pump HC1 Q2
34:Heat circuit pump HC2 Q6
35:DHW ctrl elem Q3
36:Instant heater ctrl elem Q34
38:WaterllingK34
39:2nd boiler pump speed Q27
40:Status output K35
41:Status information K36
43: Fan shutdown K38
None
6031 Relay output QX22 module 1 - None
6032 Relay output QX23 module 1 - None
6033 Relay output QX21 module 2 - None
6034 Relay output QX22 module 2 - None
6035 Relay output QX23 module 2 - None
6036 Relay output QX21 module 3 - None
6037 Relay output QX22 module 3 - None
6038 Relay output QX23 module 3 - None
