22
10. Starting operation – General
Connect the mains cable and
the foot control.
Pay attention to the
positioning!
Insert the motor cable.
Pay attention to the
positioning!
Insert the stand.
Pay attention to the
positioning!
(Maximum load
capacity 1.5 kg)
Attach the motor support
and lock it.
Insert the irrigation tubing.
Open the pump arm.
Fit the irrigation tubing.
Follow the same
sequence when removing
the irrigation tubing.
Close the pump arm.
Always place the Elcomed on a flat level surface.
Ensure that the Elcomed can be disconnected easily from the power supply.
c
d
e
b
a
