20. Technical data
Elcomed SA-310
Supply voltage: 110 – 130 V / 220 – 240 V
Permitted voltage fluctuation: ±10 %
Nominal current: 0.1 – 1.8 A / 0.1 – 0.9 A
Mains fuse: 2 x 250 V – T1.6AH
Frequency: 50 – 60 Hz
Max. power consumption: 180 VA
Max. mechanical output power: 100 W
Max. torque on the motor: 7 Ncm
Motor speed range in the nominal voltage range: 300 min
-1
– max. 50,000 min
-1
Coolant flow rate at 100 %: at least 90 ml/min
Operating mode: S3 (2min/10min)
Dimensions in mm (WxDxH): 256 x 305 x 109
Weight in kg: 7
Physical characteristics
Temperature for storage and transport: -40°C to +70°C (-40°F to +158°F)
Air humidity for storage and transport: 8 % to 80 % (relative), non condensing
Ambient temperature during operation: +10°C to +40°C (+50°F to +104°F)
Air humidity during operation: 15 % to 80 % (relative), non condensing
