5.2 SWITCHING THE INSTRUMENT ON / OFF
To switch on/off: Press the On/Off button ‘ ’.
Note: To extend battery life (time between charges) the instrument can be set to
switch off automatically after a user defined period of inactivity between 1 and
15 minutes. The default setting is 15 minutes.
5.3 SELECTING YOUR LANGUAGE
1 Press the MENU key to display the main menu.
When the instrument is switched on for the first time after despatch from the
Elcometer factory, the language selection screen will be displayed. Proceed
to Step 2.
2 Select your language using the keys.
3 Press SEL to activate the selected language.
To access the language menu when in a foreign language:
1 Switch the instrument OFF.
2 Press and hold the left hand key and switch the instrument ON.
The display will show the language selection screen with the
current language highlighted by the cursor.
3 Select your language using the keys.
4 Press SEL to activate the selected language.
5.4 CONFIGURING THE INSTRUMENT
1 Press the MENU key to display the main menu.
2 Use the keys to scroll up and down the menu items.
3 Press SEL to activate the selected option or access the sub-
menu, see Table 1.
4 Press BACK or ESC to leave the main menu or any sub-menu.
Press SEL to toggle the display backlight on or off.
Press SEL followed by or to set the beep volume;
1 (minimum) to 5 (maximum). Press OK when finished.
Press SEL followed by or to select the measurement
units;µm, mm, mil, thou or inch. Press OK when nished.
Press SEL followed by or to select the display language.
Press OK when finished.
5 GETTING STARTED (continued)
www.elcometer.com
en-9
R
