5 TECHNICAL SPECIFICATIONS
Overall Length: 96 cm (38")
Search Head Diameter: 21 cm (8")
Weight: 1.1 kg (2.5 lb)
Power Supply: 4 x 1.5 V AA cells (Alkaline) or 4 x 1.5 V NiMH rechargeable cells
(rechargeable cells must be removed from the unit before charging)
Operating Frequency: 960Hz ± 10%
H-field Strength (Hf) at 10m: 29.6dBµA/m
Operating Temperature: -10°C to 50°C (14°F to 122°F)
APPROXIMATE DETECTION RANGE
Stop Tap Box: 50 cm (19")
Fire Hydrant Cover: 87 cm (34")
Inspection Cover: 95 cm (37")
6 RELATED EQUIPMENT
Elcometer produces a wide range of concrete and coatings inspection equipment. Users of the
Elcometer 500 Metal Box Locator may also benefit from the following Elcometer products:
• Elcometer Deep Cover Metal Detector
• Elcometer Concrete Covermeters
For further information contact Elcometer, your Elcometer supplier or visit www.elcometer.com
