Selecting the Measurement Mode (T)
Selecting the Measurement Units (T)
Selecting the Filter Paper Size
The Elcometer 130 can be set to automatically detect the filter paper size
in use or this can be manually selected by the user.
To manually select the paper size, press Menu/Setup/Filter Paper Size
followed by “Full”, “Half” or “Quarter” as required. When set to “Auto”, the
gauge will automatically detect the filter paper size in use.
• For Half Size Paper; using gloves to avoid contamination - fold the
standard paper in half and cut into two along the fold line.
• For Quarter Size Paper; using gloves to avoid contamination - fold the
standard paper into quarters and cut into quadrants along the fold lines.
The Elcometer 130 will automatically adjust the reading according to the
filter paper size detected or selected, assuming that the paper is positioned
on the measurement electrodes correctly, and if manually set up, the correct
paper size is used. No manual calculations are required by the user.
When set to “Auto”, the appropriate icon is displayed when the gauge
detects a filter paper on the electrodes.
The Elcometer 130 can be used to measure soluble salts or conductivity (T).
To select the measurement mode (T), press Menu/Setup/Measurement
Mode.
2
Whilst the Elcometer 130 Model S provides readings in µg/cm , the Model T
2 2
has a choice of measurement units: µg/cm ,mg/m , µS/cm, mS/cm, ppm and
% Salinity. To select the measurement units (T), press Menu/Setup/Units.
The measurement units available depends on the measurement mode
selected:
2 2
Surface Cleanliness Mode: µg/cm or mg/m
Conductivity Mode: µS/cm, mS/cm, ppm or % Salinity
