Electra DELTA 18ST - Page 100

14-22
EXPLODED VIEWS AND SPARE PARTS LISTS
SM DELTA 1-E.0 GB
14.22 Outdoor Unit: OU7-24 RC 3PH
 Part  Description Qty
1 437045 UPPER COVER EL13 OU LARGE 1
2 433280 SIDE PANEL OU7-24 R410A 1
3 436357 SMALL ELECTRICAL COVER OU 1
4 439329 FRONT COVER/CO' OU7-35/90 EL13 1
5 437091 OU SQUARE FAN GUARD 1
6 433294 NEW BASE ASSY OU 2005 EXPORT R 1
7 433285 COIL OU7-24 HDR 1
8 4529604 AXIAL FAN D493*143 1
9 434062 MOTOR 86W,2S,OU7-24 1
10 433281 SIDE GUARD OU7-24 R410 1
11 436358 OU LEADING HANDLE 1
12 439342 MOTOR SUPPORT OU7 1
13 190443 HEATER CRANKCASE MITSUBISHI CO 1
14 433753 COMPRESSOR NN27YDAMT 1
15 433934 CAPILLARY HEATING ASSY OU7-24 1
16 433291 TUBING ASSY OU7 R410A 1
17 402494 BOARD TPHN 3C 1
18 442007 CAPACITOR 6mF 400V P1/P2 1
19 434716 THERMISTOR+CAP WTH CONNECTOR L 1
21 437278 COMPRESSOR WIRING OU7/8-3PH MI 1
22 402283 SUCTION ACCUMULATOR 3x5/8" 3. " 1
24 437229 ELECTRICAL BOX TPHN 1
25 439795 3PH MOTOR PROTECTOR 1
33 442466 VALVE COIL L700 MOLEX-SANHUA 1
44 433816 SUCTION ASSY OU7 R410A 1
