Electra DELTA 18ST - Electrical Data; Single Phase Unit Electrical Data

7-1
ELECTRICAL DATA
SM DELTA 1-E.0 GB
7. ELECTRICAL DATA
7.1 Single Phase Units
MODEL DELTA 18 DELTA 21/24 DELTA 21/24
Power Supply
To indoor To Outdoor To Outdoor
1PH-230V-50Hz 1PH-230V-50Hz 3PH-400V-50Hz
Max Current, A 11.1 14 3×6
Circuit Breaker,A 15 20 3×10
Power Supply Wiring No. X
Cross Section mm
2
3×1.5 mm
2
3×2.5 mm
2
5×1.5 mm
2
Interconnecting Cable RC
Model No. X Cross Section mm
2
5×1.5 mm
2
+ 2×0.5 mm
2
(OCT senser)
6×1.5 mm
2
+ 2×0.5 mm
2
(OCT senser)
6×1.5 mm
2
+ 2×0.5 mm
2
(OCT senser)
Interconnecting Cable ST
Model No. X Cross Section mm
2
4×1.5 mm
2
5×1.5 mm
2
+ 2×0.5 mm
2
5×1.5 mm
2
+ 2×0.5 mm
2
(OCT senser)
NOTE
Power wiring cord should comply with local lows and electrical
regulations requirements.
