To Next PageTo Next PageWhy is my Electra Alpha 9 SP R22 not cooling or heating, and only the indoor fan is working?
If your Electra Air Conditioner is only running the indoor fan and not cooling or heating, it could be due to a faulty outdoor fan motor or another fault causing the compressor overload protection to cut out. Suggested solutions include replacing the P.C.B. and removing any obstructions blocking the outdoor fan.
Why is my Electra Alpha 9 SP R22 only blowing air from the indoor fan?
If your Electra Air Conditioner is only running the indoor fan, it could be due to: * A faulty run capacitor of the outdoor fan motor. Replace the capacitor. * Shorted windings of the outdoor fan. Replace the motor.
What to do if Electra Air Conditioner has only indoor fan and compressor working?
If your Electra Air Conditioner has only the indoor fan and compressor working, it's likely that the outdoor fan is blocked. Remove any obstructions to resolve this issue.
What to do if my Electra Alpha 9 SP R22 has no air supply at the indoor unit, but the compressor operates?
If there's no air supply at the indoor unit of your Electra Air Conditioner, but the compressor is running, it could be because: * The indoor fan motor is blocked or turning slowly. Check the voltage and repair the wiring if necessary. Also, check if the fan wheel is tight enough on the motor shaft, and tighten it if needed. * The indoor fan run capacitor is faulty. * The motor windings are shorted.
What to do if Electra Alpha 9 SP R22 is in heat mode but operating in cooling?
If your Electra Air Conditioner is in heat mode but operating in cooling, it could be caused by a faulty RV coil or the RV valve being stuck. To resolve this, you can replace the RV coil or replace the reversing valve.
Why is my Electra Air Conditioner's outdoor coil freezing up in heating mode?
If the outdoor coil of your Electra Air Conditioner is freezing up in heating mode, and the heating effect in the room is poor, with the indoor fan operating, it could be due to several reasons: * A faulty outdoor thermistor: Replace the thermistor. * A faulty control cable: Repair the control cable. * Outdoor temperature below design conditions: Shut the unit off, as it cannot work properly under these conditions. * A blocked outdoor unit air outlet: Remove any obstructions.
What to do if Electra Alpha 9 SP R22 has a limited air supply at the indoor unit?
If your Electra Air Conditioner has a partial or limited air supply at the indoor unit, it's likely due to a lack of refrigerant, which may also cause a whistling noise and ice formation on the indoor unit coil in cooling mode. To fix this, charge the unit after localizing the leak.
What to do if water is dripping from the outdoor unit base of my Electra Alpha 9 SP R22 Air Conditioner in heating mode?
If water is dripping from the outdoor unit base of your Electra Air Conditioner while in heating mode, it's likely that the water drain outlet is clogged. To resolve this, open the outdoor unit cover, clean out the water outlet, and thoroughly clean the base inside.
What to do if Electra Air Conditioner has no cooling or heating, but indoor fans are working?
If your Electra Air Conditioner isn't cooling or heating, but the indoor fans are working, it could be due to a few reasons: * The overload safety device on the compressor might be cut out because of low voltage or high temperature. In this case, check for proper voltage, switch off the power, and try again after one hour. * The compressor run capacitor might be faulty; consider replacing it. * The compressor windings could be shorted, requiring you to replace the compressor.
What to do if water accumulates and overflows from the indoor unit section of my Electra Alpha 9 SP R22 Air Conditioner?
If water is accumulating and overflowing from the indoor unit section of your Electra Air Conditioner, the drain tube or spout of the drain pan is likely clogged. Disassemble the plastic drain tube from the spout of the indoor unit drain pan to clear the clog.
General| Refrigerant | R22 |
|---|---|
| Cooling Capacity | 9000 BTU/h |
| Power Supply | 220-240V, 50Hz |
| Air Flow (High) | 450 m3/h |
| Net Weight (Indoor Unit) | 9 kg |
| Power Consumption (Cooling) | 850W |
| Operating Temperature (Cooling) | 18°C to 43°C |
Describes the Alpha SP split wall-mounted units, including cooling only and heat pump models.
Highlights key technological innovations and benefits of the Alpha SP series air conditioners.
Details the components and characteristics of the wall-mounted indoor unit.
Information on the type of air filters used in the Alpha SP series.
Details on the microprocessor indoor controller and infrared remote control.
Features and installation aspects of the Alpha SP series outdoor unit.
Guidelines and specifications for connecting refrigerant tubing, including torque values.
List of manuals and documentation included with the air conditioning unit.
Tables showing compatible indoor and outdoor unit combinations for R410A and R22.
Technical specifications for Alpha 9 SP R22 and CSP 9 R22 models.
Technical specifications for Alpha 12 SP R22 and CSP 12 R22 models.
Technical specifications for Alpha 9 SP EU R410A and CSP 9 EU R410A models.
Technical specifications for Alpha 12 SP EU R410A and CSP 12 SP EU R410A models.
Technical specifications for Alpha 9 SP ISR R410A and CSPI 9 R410A RC A1 models.
Technical specifications for Alpha 12 SP ISR R410A and CSPI 12 R410A RC A1 models.
Technical specifications for ASP 9 R410A A2 ISR and CSPI 9 R410A A2 ISR models.
Technical specifications for ASP 12 R410A A2 ISR and CSPI 12 R410A A2 ISR models.
Defines operational limits for R410A and R22 refrigerants in cooling and heating modes.
Dimensional drawings and specifications for the Alpha SP 9 indoor unit.
Dimensional drawings and specifications for the Alpha SP 12 indoor unit.
Dimensional drawings for Omega models of Alpha 7 and 9 indoor units.
Dimensional drawings for Omega models of Alpha 12 indoor units.
Dimensional drawings for the Alpha 9 DF indoor unit.
Dimensional drawings for the Alpha 12 DF indoor unit.
Dimensional drawings for various CSP outdoor unit models.
Cooling and heating performance data, and pressure curves for R22 models.
Cooling and heating performance data, and pressure curves for R22 models.
Cooling and heating performance data, and pressure curves for R410A EU models.
Cooling and heating performance data, and pressure curves for R410A EU models.
Cooling and heating performance data, and pressure curves for R410A ISR models.
Cooling and heating performance data, and pressure curves for R410A ISR models.
Cooling and heating performance data, and pressure curves for R410A A2 ISR models.
Cooling and heating performance data, and pressure curves for R410A A2 ISR models.
Explanation of how sound pressure level is measured.
Octave band sound pressure level spectra for various indoor and outdoor units.
Electrical data including power supply, current, and wiring specifications for single-phase units.
Wiring diagram for ASP9 and ASP12 indoor units.
Wiring diagram for CSP9 and CSP12 outdoor units.
Diagram showing electrical connections between indoor and outdoor units.
Refrigeration flow diagrams for heat pump models.
Refrigeration flow diagrams for cooling only models.
Details on tube bending, torque values, and oil trap requirements.
Introduction to electronic control, model groups, jumpers, and legend.
Details on COMP, IFAN, OFAN, and HE operations.
Unit protections, thermistor function, fault identification, and handling.
General, specific logic, and autofan control for cooling mode.
General, IF rules, HE, RC/SH group, autofan, and OFAN rules for heating.
General description and control logic for auto mode switching.
Operation and rules for the dry mode.
Indoor coil defrost and high pressure protection during cooling.
Outdoor coil deicing and high pressure protection during heating.
Detailed flowchart for the deicing process.
Timer functions and operation.
Forced operation modes and settings.
Sleep mode functionality and adjustments.
Steps for performing controller self-tests via jumper or remote.
Explanation of unit indicators and control buttons.
Functionality of clock random delay.
Table listing common symptoms, probable causes, and corrective actions.
Exploded views and parts lists for various Alpha indoor unit models.
Exploded views and parts lists for various CSP outdoor unit models.
Lists associated installation and operation manuals for the Alpha SP series.
