1-1
INTRODUCTION
SM ASP 1-E.2 GB
1. INTRODUCTION
1.1 General
The new Alpha split wall mounted basic on comapct indoor and outdoor unit, it range
comprise the ST (cooling only) and RC (heat pump) models, as follows:
• Cooling Only:
ASP 9 410A (Flat,DF) ST / CSP 9 R410A ST;
ASP 12 R410A (Flat, DF) ST / CSP 12 R410A ST;
ASP 9 R22 (Flat,DF) ST / CSP 9 R22 ST;
ASP 12 R22 (Flat, DF) ST / CSP 12 R22 ST.
• Heat Pump:
ASP 9 R410A (Flat,DF) RC / CSP 9 R410A RC;
ASP 12 R410A (Flat, DF) RC / CSP 12 R410A RC;
ASP 9 R22 (Flat,DF) RC / CSP 9 R22 RC
ASP 12 R22 (Flat, DF) RC / CSP 12 R22 RC.
The indoor Alpha SP units are available as LED display types only, featuring esthetic
design, compact dimensions, and low noise operation.
Display type models availability:
• LED Type: ASP 9 R410A (Flat, DF), ASP 12 R410A (Flat, DF).
1.2 Main Features
The Alpha SP series benefits from the most advanced technological innovations,
namely:
• R410A/R22 models.
• Microprocessor control.
• Infrared remote control with liquid crystal display.
• Supports Indoor Air Quality features, such as –.
• Indoor large diameter cross flow fan, allowing low noise level operation.
• Bended indoor coil with treated aluminum fins and coating for improved efficiency.
• Easy access to the interconnecting tubing and wiring connections, so that removing
the front grill or casing is not necessary.
• Refrigerant pipes can be connected to the indoor unit from 5 different optional
directions.
• Automatic treated air sweep.
• Low indoor and outdoor noise levels.
• Easy installation and service.
• New package design for indoor unit, it should be based on open sleeve and open
sides
• Installation manual to be printed on one page with back and front printing
• One RC simply manual printing on two side as the standard
