Electra Alpha 9 SP R22 - Product Data Sheets by Model; Alpha 9 SP R22; CSP 9 R22 Data

2-1
PRODUCT DATA SHEET
SM ASP 1-E.2 GB
2. PRODUCT DATA SHEET
2.1 Alpha 9 SP R22 / CSP 9 R22
Model Indoor Unit ASP 9(ASP FLAT,ASP DF)
Model Outdoor Unit CSP 9
Installation Method of Pipe Flared
Characteristics Units Cooling Only Cooling Heating
Capacity
(4)
Btu/hr 8770 8770 9550
kW 2.57 2.57 2.80
Power input
(4)
kW 0.94 0.94 0.85
EER (Cooling) or COP(Heating)
(4)
W/W 2.73 2.73 3.30
Energy efficiency class D D C
Power supply
V 220-230
Ph 1
Hz 50
Rated current A 4.4 4.4 4.0
Power factor
0.95 0.95 0.95
Prated (IDU)
W 27
Prated (IDU+ODU)
W 1090
Starting current A 26
Circuit breaker rating A 10
INDOOR
Fan type & quantity Crossflow x 1
Fan speeds H/M/L RPM 1250/-/1050
Air flow
(1)
H/M/L m3/hr 450/-/350
External static pressure Min Pa 0
Sound power level
(2)
H/M/L dB(A) 52/-/48
Sound pressure level
(3)
H/M/L dB(A) 40/-/35
Moisture removal l/hr 1
Condenstate drain tube I.D mm 16
Dimensions WxHxD mm 680*180*250
Net Weight kg 6
Package dimensions WxHxD mm 740x310x248
Packaged weight kg 8.5
Units per pallet units 36
Stacking height units 9 levels
OUTDOOR
Refrigerant control Capillary tube
Compressor type,model Rotary,TOSHIBA PH170X1C-4DZDE3
Fan type & quantity Propeller(direct) x 1
Fan speeds H RPM 900
Air flow H m3/hr 1265
Sound power level H dB(A) 62 63
Sound pressure level
(3)
H dB(A) 52 53
Dimensions WxHxD mm 610x520x240
Net Weight kg 26 26.5
Package dimensions WxHxD mm 725*550*355
Packaged weight kg 29 29.5
Units per pallet Units 12
Stacking height units 4 levels
Refrigerant type R22
Refrigerant chargless distance kg(4m) 0.63kg
Additional charge 4m<Lin<8m:+5g/m; Lin>8m:+15g/m
Connections between units
Liquid line In.(mm) 1/4”(6.35)
Suction line In.(mm) 3/8”(9.53)
Max.tubing length m. Max.15
Max.height
difference
m. Max.7
Operation control type Remote control
Heating elements (Option) kW
Others
(1)
Airflow in ducted units;at nominal external static pressure.
(2)
Sound power in ducted units is measured at air discharge.
(3)
Sound pressure level measured at 1-meter distance from unit.
(4)
Rating conditions in accordance to ISO 5151 and ISO 13253 (for ducted units).
(5)
Declaration torlenance is in accordance with EN14511.
