Electra DELTA 18ST - Cooling Only Model Refrigeration Diagrams

10-4
REFRIGERATION DIAGRAMS
Service Manual - ALPHA
10.2 Cooling Only Models
10.2.1 DELTA 18, 21, 24 R410A
Outdoor coil
Strainer
Capillary
tube
Compressor
Service
port
OUTDOOR UNIT
connection
Valves
Flared
Indoor coil
Sensor
INDOOR UNIT
