12-34
CONTROL SYSTEM
SM DELTA 1-E.0 GB
12.2 System Diagnostics
Pressing Mode button for 5-10 seconds in SB or any other operation mode will activate
diagnostic mode by the acknowledgment of 3 short beeps and lighting of COOL and
HEAT LEDs.
In diagnostic mode, system problems will be indicated by blinking of Heat & Cool LEDs.
The coding method will be as follow:
Heat led will blink 5 times in 5 seconds, and then will be shut off for the next 5 seconds.
Cool led will blink during the same 5 seconds according to the following table:
No Problem ○○○○○
1 RT1 is disconnected ○●●●●
2RT1 is shorted ○●●●○
3 (Reserved) ○●●○●
4 RT2 is disconnected ●○●●●
5RT2 is shorted ●○●●○
6 (Reserved) ●○●○●
7 RT2 temp reading doesn’t change ●○●○○
8 RT3 is disconnected ●●○●●
9RT3 is shorted ●●○●○
10 (Reserved) ●●○○●
11 RT3 temp reading doesn’t change ●●○○○
12 RT2 & RT3 temp reading doesn’t change ●○○○○
○ - ON, ● - OFF
Notes:
1. If faults occur in more than one thermistor (except case number 12 on the
table above), only one fault will be indicated according to the following order:
RT3, RT2, RT1.
2. A/C will jump out to normal mode if sending a command by the R/C in the
system diagnostics mode. If this command from the R/C contain a Group ID, this
ID will become the new Group ID of the ELCON unit.
