14-2
EXPLODED VIEWS AND SPARE PARTS LISTS
SM DELTA 1-E.0 GB
14.2 Indoor Unit: DELTA 18, 21, 24
. Item Description Quan.
1 465020098 Front Plate/Delta 18&24 Fagor 1
2 452919800 Filter 2
3 4518113 Fiber Filter Assy. 1
4 465720204 Silk-Screen Front Frame Assy./Delta 18-24 Fagor Electra 1
5 452919600 Screw cover 3
6 462350084 Evaporator Assy./WNG21/24 R410A 1
453046600 Evaporator Assy./WNG18 R410A 1
7 452917300 Air outlet 1
8 465210009 Drain Pipe for Israel /WNG18/24/30 1
9 452917500 Horizontal flap A 1
9 452917600 Horizontal flap B 1
10 452930700 Vertical flap A 12
10 452918200 Vertical flap B 2
11 4518662 Bearing assy fan 1
12 453024900 Impeller fan 1
13 453053800 Base assy./WNG18 1
14 452920100 Mount bracket/WNG-18 1
15 452919400 Joint/Unit housing 1
16 453134300R Resin Motor 26W/WNG24 LED (DELTA21,24) 1
453116500R Resin Motor 18W/WNG18 LED (DELTA18) 1
17 452918800 Cover/motor 1
18 453050300 STEP MOTOR B 1
20 4519147 Power Cord Clip 1
20 452919200 Tie/connection Wire 1
21 467300197R Display Board/Delta 18 F 1
22 452919100 Support/sensor 1
22 4516263 SENSOR BASE 1
23 467300201R Controller/Delta F 18 S/W:10V14 1
24 438082 Thermistor Indoor coil BLACK. 1
25 467400025 Indoor Air Inlet Temperature Sensor 1
26 452919500 Cover/terminal 1
28 4520416 Defrost cable EXPORT UNITS. 1
29 438600R Remote controller RC3-RC 973-600-00 1
30 4518651 Cover Side Motor 1
31 453057900 Gear BOX ASSY 1
34 452918700 Support/horizontal louver 2
36 4518657 TUBE LOCK 1
