14-10
EXPLODED VIEWS AND SPARE PARTS LISTS
SM DELTA 1-E.0 GB
14.10 Outdoor Unit: GC 21 ST
 Part  Description Qty
1 4517144 COVER PP+UV 1
2 452795700 PAINTED LEFT CABINET ASSY 1
3 452989200 Base welding plate assy. 1
4 4516786 PAINTED RIGHT CABINET ASSY 1
5 4516985 Partition Plate 1
6 455000507 Compressor Capacitor With Screw 50uF (CBB65) 1
7 455000104 Double patch Capacitor for fan motor 4uF (CBB61S) 1
8 204107 Cable clip Nylon 2
9 4522469 4 LEVEL TERMINAL BLOCK 1
10 4521744 3 Poles Terminal Block (4mm2) 1
11 4521733 3 Poles Terminal Block ( 6mm2) 1
12 4521340 Controller Box 1
13 4525427 Clip for capacitance(d=50) 1
14 452975900 Compressor assy.PA240X2CS-4KU1 1
15 4519000 Spring fo compressor heater 1
16 4517345 COMPRESSOR WIRE ASSY. 2.5mm2 1
17 452988900 Heater for compressor 1
18 4516766 PAINTED VALVE PLATE ASSY 1
19 4526513 LOW PRESS VALVE (R410A) 1
20 4526514 Hight press valve(R410A) 1
21 452891100 Filter assy 1 1
22 452891200 Filter assy 2 1
23 4523145 R.lifter 1
24 463600001 Capillary welding assy. 1
25 4523338 Accumulator assy 1
26 452977300 Low pressure pipe 1
27 452976200 Suction pipe 1 for PA240 1
28 4526291 Muffler 1
29 4525938 PAINTED RIGHT-BACK CABINET ASSY 1
30 452977100 Condenser pipe assy. 1
31 453018400 Discharge pipe 2 1
32 4517028 PAINTED LEFT-BACK GRILL 1
33 4516758 SMALL HANDLE 1
34 452976000 Discharge pipe 1 1
35 452897800 Condenser and distributor welding assy. 1
36 452988800 Insulation for compressor 1
37 4526509 MOTOR BRAKECT (new) 1
38 4526864 motor YYK85E-6 1
39 452907400 Hook for condenser 1
40 4526510 FAN D=460mm (3 blade) 1
41 4523141 Hexagon locked nut M10 1
42 4516788 PAINTED TOP COVER ASSY 1
