14-12
EXPLODED VIEWS AND SPARE PARTS LISTS
SM DELTA 1-E.0 GB
14.12 Outdoor Unit: GC 24 ST
 Part  Description Qty
1 4517144 FAN COVER PP+UV 1
2 452795700 PAINTED LEFT CABINET ASSY 1
3 452881901 Base plate paint assy. 1
4 4516786 PAINTED RIGHT CABINET ASSY 1
5 4516985 Partition Plate 1
6 455000301 Compressor Capacitor 55uF (CBB65) 1
7 455000104 Double patch Capacitor for fan 1
8 204107 Cable clip Nylon 2
9 4522469 4 LEVEL TERMINAL BLOCK 1
10 4521744 3 Poles Terminal Block (4mm2) 1
11 4521733 3 Poles Terminal Block ( 6mm2) 1
12 4521340 Controller Box 1
13 4525427 (d=50) clip for capacitance 1
14 452864700 Compressor NN27VBAMT assy. for 1
15 4519000 Spring fo compressor heater 1
16 4517345 COMPRESSOR WIRE ASSY. 2.5mm2 1
17 452892100 Heater for compressor 1
18 4516766 PAINTED VALVE PLATE ASSY 1
19 4526513 LOW PRESS VALVE (R410A) 1
20 4526514 Hight press valve(R410A) 1
21 452891100 Filter assy 1 1
22 452891200 Filter assy 2 1
23 4523145 R.lifter 1
24 452901200 Capillary welding assy. 1
25 452891400 Accumulation assy 1
26 452893600 Suction pipe 1
27 452883600 Suction pipe assy. 2 1
28 4526291 Muffler 1
29 4525938 PAINTED RIGHT-BACK CABINET ASSY 1
30 452893700 Discharge tube 1 1
31 4517028 PAINTED LEFT-BACK GRILL 1
32 4516758 SMALL HANDLE 1
33 452893800 Discharge pipe 2 1
34 452882900 Condenser and distributor 1
35 452891300 Insulation for compressor NN27 1
36 4526509 MOTOR BRAKECT (new) 1
37 4526864 motor YYK85E-6 1
38 452907400 Hook for condenser 1
39 4526510 FAN D=460mm (3 blade) 1
40 4523141 M10 Hexagon locked nut M10 1
41 4516788 PAINTED TOP COVER ASSY 1
