EXPLODED VIEWS AND SPARE PARTS LISTS
SM DELTA 1-E.0 GB
14.14 Outdoor Unit: GC 24 RC
 Part  Description Qty
1 4517144 FAN COVER PP+UV 1
2 452795700 PAINTED LEFT CABINET ASSY 1
3 452881901 Base plate paint assy. 1
4 4516786 PAINTED RIGHT CABINET ASSY 1
5 4516985 Partition Plate 1
6 455000301 Compressor Capacitor 55uF (CBB65) 1
7 455000104 Double patch Capacitor for fan 1
8 204107 Cable clip Nylon 2
9 4524907 contactor (CJX9B-25S/01) 1
10 4521744 3 Poles Terminal Block (4mm2) 1
11 4522469 4 LEVEL TERMINAL BLOCK 1
12 4521733 3 Poles Terminal Block ( 6mm2) 1
13 4521340 Controller Box 1
14 4525427 (d=50) clip for capacitance 1
15 452864700 Compressor NN27VBAMT assy. for 1
16 4519000 Spring fo compressor heater 1
17 4517345 COMPRESSOR WIRE ASSY. 2.5mm2 1
18 452862100 Base Bom for KCR-50M(SHX33SC4-U 1
18 452892100 Heater for compressor 1
19 4516766 PAINTED VALVE PLATE ASSY 1
20 4526513 LOW PRESS VALVE (R410A) 1
21 4526514 Hight press valve(R410A) 1
22 452891100 Filter assy 1 1
23 452891200 Filter assy 2 1
24 4523145 R.lifter 1
25 452891600 Single-way welding assy 1
26 452891400 Accumulation assy 1
27 452883700 Suction pipe 1
28 452883800 Low pressure pipe assy. 1
29 452883500 Condenser pipeassy. 1
30 4526291 Muffler 1
31 4525938 PAINTED RIGHT-BACK CABINET ASSY 1
32 4526522 FOUR-WAY VALVE R410A 1
33 4526589 4-Way Valve Coil FOR R410A 1
34 452890700 Dischage pipe 1 1
35 452882800 4-way welding assy. 1
36 4517028 PAINTED LEFT-BACK GRILL 1
37 4516758 SMALL HANDLE 1
38 452890800 Discharge tube 2 1
39 452882900 Condenser and distributor 1
40 452891300 Insulation for compressor NN27 1
41 452883600 Suction pipe assy. 2 1
42 4526509 MOTOR BRAKECT (new) 1
43 4526864 motor YYK85E-6 1
44 452907400 Hook for condenser 1
45 4526510 FAN D=460mm (3 blade) 1
46 4523141 M10 Hexagon locked nut M10 1
47 4516788 PAINTED TOP COVER ASSY 1
48 452925700 Pressure switch 4.2MPa/3.7MPa 1
49 192106 Relay JQX-13F/220-2Z5 OR VE-R02 2Ca2 1
