14-16
EXPLODED VIEWS AND SPARE PARTS LISTS
SM DELTA 1-E.0 GB
14.16 Outdoor Unit: OU7-24 RC 1PH
No Part No Description Qty
1 437045 UPPER COVER EL13 OU LARGE 1
2 433280 SIDE PANEL OU7-24 R410A 1
3 436357 SMALL ELECTRICAL COVER OU 1
4 439329 FRONT COVER/CO' OU7-35/90 E 1
5 437091 OU SQUARE FAN GUARD 1
6 433705 NEW BASE ASSY OU 2005 LOCAL 1
7 433285 COIL OU7-24 HDR 1
8 4529604 AXIAL FAN D493*143 1
9 434062 MOTOR 86W,2S,OU7-24 1
10 433281 SIDE GUARD OU7-24 R410 1
11 436358 OU LEADING HANDLE 1
12 439342 MOTOR SUPPORT OU7-24 1
13 190443 HEATER CRANKCASE MITSUBISHI 1
14 433293 COMPRESSOR NN27VBAMT 1
15 433934 CAPILLARY HEATING ASSY OU7-24 1
16 433291 TUBING ASSY OU7 R410A 1
17 402495 BOARD TPHN 5B 1
18 442007 CAPACITOR 6mF 400V P1/P2 1
19 434716 THERMISTOR+CAP WTH CONNECTO 1
20 442011 CAPACITOR 25mF 400V P1/P2 1
20 442016 CAPACITOR 55mF 400V P1/P2 1
21 437274 COMPRESOR WIRING OU7/8-1PH 1
22 402283 SUCTION ACCUMULATOR 3x5/8" 1
24 437229 ELECTRICAL BOX TPHN 1
33 442466 VALVE COIL L700 MOLEX-SANHU 1
44 433816 SUCTION ASSY OU7 R410A 1
