Electra DNG 100 - EMD 125 DCI; OU12 5 HP DCI Specifications

2-4
PRODUCT DATA SHEET
SM OU12HP 2-E.2 GB
2.4 EMD 125 DCI / OU12 5HP DCI
Model Indoor Unit EMD 125 DCI
Model Outdoor Unit OU12 5HP DCI
Installation Method DUCTED
Characteristics Units Cooling Heating
Capacity - Nominal (Minimum ~ Maximum)
(1)
Btu/hr 42,650 (11,940-47,770) 47,770 (12,280-54,590)
kW 12.5 (3.5-14.0) 14.0 (3.6-16.0)
Power input - Nominal (Minimum ~ Maximum)
(1)
kW 4.1 (1.65-5.5) 4.1 (1.1-5.2)
EER (Cooling) or COP(Heating)
(1)
W/W 3.05 3.4
Energy efficiency class B B
Power supply V/Ph/Hz 230 / 1 / 50
Rated current A 18.8 18.6
Starting current A 10
Circuit breaker rating A 32
INDOOR
Fan type & quantity Centrifugal x 1
Fan speeds H/M/L RPM 930 / 830 / 740
Air flow
(2)
H/M/L m3/hr 2500 / 2100 / 1600
External static pressure Min-Max Pa 20-100
Sound power level
(3)
H/M/L dB(A) 72 / 68 / 64
Sound pressure level
(4)
H/M/L dB(A) 54 / 51 / 45
Moisture removal (Nominal) l/hr 3.8
Condensate drain tube I.D mm 19
Dimensions WxHxD mm 1150X400X700
Weight kg 46
Package dimensions WxHxD mm 1195X440X730
Packaged weight kg 50
Units per pallet units 8
Stacking height units 4
OUTDOOR
Refrigerant control Electronic Expansion Valve
Compressor type, model Scroll
Motor type DCBL Inverter
Fan type & quantity Axial 2 x 493 Ømm
Fan speeds H/L RPM 900 – 100 (Continuous)
Air flow Max m3/hr 5,700
Sound power level
(3)
Nom C/H dB(A) 69 / 70
Sound pressure level
(4)
Nom C/H dB(A) 56 / 58
Dimensions WxHxD mm 900X1255X340
Weight kg 110
Package dimensions WxHxD mm 985X1395X435
Packaged weight kg 120
Units per pallet Units 1
Stacking height units 1
Refrigerant type R410A
Refrigerant charge(standard connecting
tubing length)
Kg(m) 3.3 / 30
Additional charge per 1 meter g/m 38
Connections
between units
Liquid line In.(mm) 3/8" (9.52)
Suction line In.(mm) 3/4" (19.0)
Max.tubing length m. 70
Max.height difference m. 30
Operation control type LCD Remote control
Heating elements kW
—
Others
(1)
Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units).
(2)
Airflow in ducted units; at nominal external static pressure.
(3)
Sound power in ducted units is measured at air discharge.
(4)
Sound pressure level measured at 1.0 meter distance from unit.
