Electra DNG 100 - CD 140 DCI; OU12 6 HP DCI Specifications

2-5
PRODUCT DATA SHEET
SM OU12HP 2-E.2 GB
2.5 CD 140 DCI / OU12 6HP DCI
Model Indoor Unit CD 140 DCI
Model Outdoor Unit OU12 6HP DCI
Installation Method DUCTED
Characteristics Units Cooling Heating
Capacity - Nominal (Minimum ~ Maximum)
(1)
Btu/hr 47,770 (15,700 - 56,300) 54,600 (12,600 – 63,100)
kW 14.0 (4.6 – 16.5) 16.0 (3.7 – 18.5)
Power Input - Nominal (Minimum ~ Maximum)
( (1)
W 4,200 (1,500 - 6,000) 4,400 (1,200 - 5,500)
COP
(1)
W/W 3.3 3.6
Energy Efficiency Class - A A
Power Supply V/Ph/Hz 220-240/1/50
Rated Current (Nominal) A 21.6 20.3
Starting Current A <10
Circuit Breaker Rating A 32
INDOOR
Fan Type & Quantity CENTRIFUGAL x2
Fan Speed H/M/L RPM 1,160 1,120 1,000
Airflow
(2)
H/M/L m
3
/hr 3,300 2,900 2,000
External Static Pressure
Min-
Nom-
Max
Pa 80-140-200
Sound Power Level
(3)
H/M/L dB (A) 73 71 66
Sound Pressure Level
(4)
H/M/L dB (A) 58 55 50
Moisture Removal (Nominal) L/hr 4.0
Condensate Drain Tube I.D. mm 19
Dimensions W/H/D mm 1350 400 640
Weight kg 75
Package Dimensions W/H/D mm 1510 440 785
Packaged Weight kg 82
Units per Pallet Units 5
Stacking Height Units 5
OUTDOOR
Refrigerant Control Electronic Expansion Valve
Compressor Type, Model Twin-Rotary
Motor type DCBL Inverter
Fan Type & Quantity Axial 2x 493mm
Fan Speed RPM 900-100 (continuous)
Airflow Max m
3
/hr 5,700
Sound Power Level Nom dB (A) 68 70
Sound Pressure Level
(4)
Nom dB (A) 56 58
Dimensions W/H/D mm 900 1255 340
Weight kg 110
Package Dimensions W/H/D mm 985 1395 435
Packaged Weight kg 120
Units per Pallet Units 1
Stacking Height Units 1
Refrigerant Type R410A
Refrigerant Chargeless Distance kg/m 3.8 / 30
Additional Charge Per 1 Meter g/m 80
Connections
Between Units
Liquid Line In 3/8”
Suction Line In 3/4”
Max. Tubing Length m 70
Max. Height Difference m 30
Operation Control Type LCD Remote Control
Heating Elements kW BH 70W - optional
Others
(1)
Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units).
(2)
Airflow in ducted units; at nominal external static pressure.
(3)
Sound power in ducted units is measured at air discharge.
(4)
Sound pressure level measured at 1.0 meter distance from unit.
