12.9.2 ODU Model Dependent Parameters
# Name
M
DCI112
N
DCI140
O
DCI160
Unit
1.
MinFreqC 25 25 20 Hz
2.
MaxFreqC 75 85 70 Hz
3.
MinFreqH 25 25 20 Hz
4.
MaxFreqH 90 100 75 Hz
5.
Step1Freq 40 40 40 Hz
6.
Step2Freq 90 90 90 Hz
7.
Step3Freq 120 120 120 Hz
8.
NightRPM 60 60 60 *10RPM
9.
CTTOH1 87 87 87 °C
10.
CTTOH2 90 90 90 °C
11.
CTTOH3 92 92 92 °C
12.
CTTOH4 95 95 95 °C
13.
ACCOC1 16.6 23.6 23.0 A
14.
ACCOC2 17.2 24.2 23.8 A
15.
ACCOC3 17.6 24.6 24.4 A
16.
ACCOC4 18.0 25.0 25.0 A
17.
DCCOC1 20.0 20.0 - A
18.
DCCOC2 20.8 20.8 - A
19.
DCCOC3 21.4 21.4 - A
20.
DCCOC4 22.0 22.0 - A
21.
EEVMinOperOpenC 60 60 60 step
22.
EEVMaxOperOpenC 400 400 480 step
23.
EEVMinOperOpenH 60 60 60 step
24.
EEVMaxOperOpenH 480 480 480 step
25.
OATLimitC 25 25 25 °C
26.
OATLimit1H 4 4 4 °C
27.
OATLimit2H 15 15 15 °C
28.
MaxFreqAsOATC 70 70 60 Hz
29.
MaxFreqAsOAT1H 90 90 80 Hz
30.
MaxFreqAsOAT2H 60 60 60 Hz
31.
NormAccel 1 1 1 Hz/s
32.
NormDecel 1 1 1 Hz/s
33.
OCTExitDeicer 12 12 12 °C
34.
MaxDeicerTime 12 12 12 minute
35.
DryContactDis 1 1 1 Byte
36.
NightRPS 60 60 55 RPS
