Electra GCN 12 - Page 413

14-136
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-03 Service Manual - WNG
14.3.33 Outdoor Unit GC 30 RC
Item Code Item Desc Quantity
Drawing
Number Effective From Effective To
4523657 PAINTED TOP COVER ASSY 1 1 07-Apr-03 Active
4522600 Left Handle 1 2 07-Apr-03 Active
4522604 outlet grid 1 3 07-Apr-03 Active
4523652 PAINTED LEFT CABINET ASSY 1 4 07-Apr-03 Active
4523408 BASE ASSY 1 5 07-Apr-03 Active
4522599 Partition 1 6 07-Apr-03 Active
4522601 Right Handle 1 7 07-Apr-03 Active
4522594 Right front plate 1 8 07-Apr-03 Active
4522014 ACCUMULATOR 1 9 07-Apr-03 Active
4523646 Oil separator welding assy. 1 10 07-Apr-03 Active
4523654 PAINTED RIGHT BACK CABINET ASSY 1 11 07-Apr-03 Active
4523759 COMPRESSOR CABLE 1 12 07-Apr-03 Active
4522930 Valve plate 1 13 07-Apr-03 19-Aug-03
4526081 Valve plate for GC-30RC 1 13 19-Aug-03 Active
4523389 Low pressure cut-off valve 1 14 07-Apr-03 19-Aug-03
4525711 liquid-valve for GC-30RC 1 14 19-Aug-03 Active
4523388 High pressure cut-off valve 1 15 07-Apr-03 Active
4524017 LG Compresser assy. SQ040PAA 1 16 07-Apr-03 Active
4518410 COMPRESSOR ISOLATION 1 17 07-Apr-03 19-Aug-03
4523766 COMPRESSOR ISOLATION (LG, D=1 1 17 19-Aug-03 Active
4518782 TOP COVER INSULATION FOR COMP 1 18 07-Apr-03 19-Aug-03
4522602 Valve Cover 1 18 19-Aug-03 Active
4522602 Valve Cover 1 19 07-Apr-03 19-Aug-03
4516429 Out sensor Black 1 19 19-Aug-03 Active
4516429 Out sensor Black 1 20 07-Apr-03 19-Aug-03
4525213 COMPR. SUB HEATER 1 20 19-Aug-03 Active
4520870 Compressor heater 1 21 07-Apr-03 19-Aug-03
4523757 single-way and filter 1 21 19-Aug-03 Active
4523757 single-way and filter 1 22 07-Apr-03 19-Aug-03
4523763 SQ040PPA) 1 22 19-Aug-03 Active
4523656 BACK GRID PAINT ASSY 1 23 07-Apr-03 Active
4523962 SUCTION TUBE 1 23 07-Apr-03 19-Aug-03
4523762 SQ040PAA) 1 24 19-Aug-03 Active
4519751 pressure switch(3.0MPa off/2.4MPa ON) 1 25 07-Apr-03 Active
4523641 Discharge Tube 1 (12.7*0.7) (For C- 1 25 07-Apr-03 19-Aug-03
204107 Cable clip Nylon 1 26 07-Apr-03 Active
4523750 4-way valve welding assy. (GC-30 1 27 19-Aug-03 Active
4523960 4-way valve welding assy. (GC- 1 28 07-Apr-03 19-Aug-03
4523749 Condenser welding assy. GC-30 1 28 19-Aug-03 Active
4525209 Condenser welding assy. GC- 1 29 07-Apr-03 19-Aug-03
4525427 (d=50) clip for capacitance 1 29 19-Aug-03 Active
4517048 TERMINAL BLOCK OF NUETRAL 1 30 07-Apr-03 19-Aug-03
4523953 Capacitor 60uF 1 30 19-Aug-03 29-Dec-03
455000302 Compressor Capacitor 60uF (CBB65) 1 30 29-Dec-03 Active
4517308 TERMINAL BLOCK OF POWER SUPPLY 1 31 07-Apr-03 19-Aug-03
4524907 contactor (CJX9B-25S/01) 1 31 19-Aug-03 Active
4517006 TERMINAL BLOCK OF CABLE 1 32 07-Apr-03 19-Aug-03
4523291 SOFT STARTER EHK946-001-11 1 32 19-Aug-03 Active
4518056 CONTACTOR EB16 OR D1801N 1 33 07-Apr-03 19-Aug-03
4522605 Motor support 1 33 19-Aug-03 Active
4519695 MIX AND MISSING PHASE DEVICE 1 34 07-Apr-03 19-Aug-03
4523647 Fan Motor YYK80F-6 850rpm 1 34 19-Aug-03 Active
4522605 Motor support 1 35 07-Apr-03 19-Aug-03
4518042 Capacitor 3.5uf 1 35 19-Aug-03 08-Jan-04
455000103 Double patch Capacitor for fan 1 35 08-Jan-04 Active
4523648 Fan Motor YYK95C-6 950rmp 1 36 07-Apr-03 19-Aug-03
4523386 490mm OUTDOOR FAN 1 36 19-Aug-03 Active
4517007 FAN CAPACITY 6uF 1 37 07-Apr-03 19-Aug-03
4523758 Nut M8 left 1 37 19-Aug-03 Active
4523386 490mm OUTDOOR FAN 1 38 07-Apr-03 19-Aug-03
4525933 control box 1 38 19-Aug-03 Active
4523758 Nut M8 left 1 39 07-Apr-03 19-Aug-03
4523385 CONTROL BOX (GC-30/34) 1 40 07-Apr-03 19-Aug-03
