Electra WMN9 - Wiring Diagram Legend (SE 3172;3173)

To Next Page

To Previous Page

1818

WMTWMT

WMT

090914 RC090914 RC

090914 RC

High THigh T

High T

echech

ech

MFA/MFB COMPRESOR

FFA/FFB EXTERNAL PROTECTION MFA/B

CFA/CFB CVA/CVB CAPACITOR

EFA/EFB CRANKCASE HEATER

PCB ELECTRONIC CONTROLL-BOARD

TA/TB TRANSFORMER 230/12V

OCT1...OCT4 DEFROSTING SENSOR

OAT AMBIENCE SENSOR

SV-A1...SV-B3 / SVA3 A..B SOLENOID VALVE

ORV-A1...ORV-B2 REVERSING VALVE

J1/J2/J0 JUMPER

R1...R4 DUMMY PROBE

HPA/HPB AUTOMATIC HIGH PRESSURE PRESSOSTAT

KA1/KA2/ KA3/KA4 KHPA/KHPB RELAY

MVA/MVB MOTEUR CONDENSING FAN MOTOR

FVA/FVB INTERNAL PROTECTION OF MV A/B

XIU1...XIU4 INDOOR UNIT TERMINAL

X MAIN TERMINAL STRIP

QF1-2/3-4 QF 1/2-3 HEATER FUSE SWITCH (NOT FITTED)

WIRING DIAGRAM LEGEND SE 3172/3173

CODE: 399734
