4. Make sure the unit is upright and there are no obstructions
to the air inlets and outlet grills
5. Fix the other end of the hose to the air-outlet window kit
Note:
The window kit is only designed to be installed with sliding or sash windows or doors. The window kit is not
designed or to be used with any other style of windows. However the fish tail adaptor can be used with most windows
/ doors. When using the fishtail adaptor instead of sash window kit or wall ducting ensure that the opening left is as
small as possible.
The best form of installation is through a wall duct.
Important safeguards
The length of the soft hose extends from 28 cm to 150 cm. If hose is extended above this length
the unit may malfunction and this can invalidate the warranty.
The outlet vent must be well ventilated and not
obstructed as this will cause the unit to overheat. Avoid
bending the air hose more than 30 degrees. If the unit
does not reach the venting point it may be installed on a
flat stable surface such as a table or platform. Castors may
be removed and rubber mat installed underneath.
