ElectrIQ COMPACT - OPERATION AND SETTINGS; Control Panel and Remote Functions

Page 8 of 14
OPERATION AND SETTINGS
This portable air conditioner boasts three functions: cooling, dehumidifying and fan.
The fan has three speeds: high, medium and low
Temperature range settings are: 17-30
0
C
The unit will also display operating function, temperature, fault diagnostic and protective functions
on the LCD screen.
Control instruction
：
：：
：
1. Power key Press the key to turn ON/OFF the A/C.
2. Mode key Press the key to choose cooling, fan, dry and auto-mode.
3. “DOWN” key Press the key in cooling mode to reduce the setting temperature,
press it in timing mode to adjust timer ON/OFF time. Press “Up” and “Down” keys
simultaneously on the control panel to switch Fahrenheit and Celsius scale.
4. Temperature/ time display window
This window displays the adjusted temperature and time.
5. “UP” key
Press the key in cooling mode to increase the setting temperature, press it in
timing mode to adjust timer ON/OFF time.
6. Fan speed key Press the key to choose high/ mid/low fan speed.
7. Timer key
Press the key in standby mode to set TURN-ON time (0-24hrs)
Press this key to set TURN-OFF time when the unit is on (0-24hrs)
8. Remote controller receiving window
This window displays the adjusted temperature and time.
9.
9. 9.
9. ℃
℃℃
℃/℉
℉℉
℉ switching key Press the key to switch ℃ and ℉.
10. Auto-swing key Press this key at any time after turning on the A/C to swing
the wind louvers automatically.
11. Child Lock Press the lock key to lock the control. Press and hold the unlock
key to unlock the control
Turbo cool mode (optional) Under cooling mode press TIMER and UP buttons at the same time to enter
turbo mode. Unit will cool regardless of set temperature. Fan speed is high, and it cannot be adjusted.
Sleep mode (optional) Press TIMER and DOWN button at the same time under cooling to enter sleep
mode. Under this mode, the set temperature increases by 1⁰C after 2 hrs of operation, than after
another 2 hrs will increase by another 1⁰C than will not change at all. Fan is fixed to quiet low speed.
Dry mode (dehumidifier) if this function is selected the unit will function as a dehumidifier if room
temperature is >15⁰C. If room temperature is <13⁰C the compressor will be turned off. Temperature is
not adjustable and fan will run on low speed. The hot air hose must be disconnected and the unit
should be permanently drained either using a gravity fall or an uplift water pump (not supplied). If
permanent drainage is not used the internal tank will fill and FL error code will require to empty the
tank.
