ElectrIQ P12C - Technical Data

Page 17 of 18
TECHNICAL DATA
P12C
P12HPW
Capacity
Cooling: 12,000 BTU
Cooling: 12,000 BTU
Heating:11,000 BTU
Rated Input
Cooling: 1345W
Cooling: 1345W
Heating: 1391W
Running Current
Cooling: 6.0A
Cooling: 6.0A
Heating:6.3A
Noise (sound power)
≤65dB(A)
≤65dB(A)
Permitted Excessive
Operating
Pressure
1.0/2.6 MPa
1.0/2.6 MPa
Maximum Allowable
Pressure
1.2/3.2 MPa
1.2/3.2 MPa
Power Supply
220-240V/50Hz
220-240V/50Hz
Net Weight
26Kg
26Kg
Refrigerant Quantity
210g
210g
Dimension(L*D*H)
440x335x715 mm
440x335x715 mm
Unit must be vented outside when in Air Cooling and Heating mode.
For the purposes of EU regulation EN12102 this is a local air
conditioner and produces less than 65dB(A) sound energy.
