32 en | Recommended configurations EVOLVE Portable Column Loudspeaker
2019-12 | 03 | F.01U.381.064 User manual Electro-Voice
8 Recommended configurations
8.1 Stereo pair of EVOLVE 30M systems
LI NE LI NE
L
R
Figure8.1: R = Right; L = Left
Notice!
The direction of the arrow indicates the signal path.
Mode: Music
MASTER SPEAKER (L) MIX OUT: R
SATELLITE SPEAKER (R): INPUT 5 (MONO)
Tab.8.3: DSP settings for the portable column system
Notice!
Stereo connection from device to the MASTER SPEAKER can be made with hard wires into
the stereo INPUT 5/6 or via Bluetooth ( R ) into stereo Bluetooth (R ) INPUT 7/8.
