23
IMTP(D) 2.2 – ITTP(D) 2.2/4.0/5.5/7.5 - ELECTROIL
ENG
Control Type
1. Mode:
1.1 Pump Speed
1.2 Pump
Pressure
1.3 Master-Slave
RS485
1.4 Differential
Pressure
1.5 MasterSlave
DP
2. Pumps number
(2..8)
3. Code (0..7)
4. Reference Speed
[RPM]
5. Start-Stop Input
*(not for 2.2M)
6. Pressure
reference Input *(not
for 2.2M)
1. Set Control Type mode:
1.1 Pump speed control: directly
regulation of the speed in
absence of pressure sensor;
security stop for minimum flow
and dry working conditions,
only with manually re-start.
1.2 Single Pump pressure control
1.3 Master-Slave Group
functioning for the absolute
pressure control by RS485
serial bus
1.4 Differential pressure control for
a single pump: dP=P2 (outlet)
– P1 (inlet);
1.5 Differential pressure control in
group by RS485 serial bus;
5 Pumps Number: Number of
pumps (for group functioning
mode 1.3 or 1.5)
3. Code
4. Reference Speed value (only for
speed control mode)
5. Start-Stop Input:
5.1 Keyboard;
5.2 Remote (for connections, see
par. 5.6.8) *(not for 2.2M);
6 Pressure reference Input:
6.1 Keyboard;
6.2 0-10V Input (for connections,
see par. 5.6.9);
16. 4-20 mA Input (for connections,
see par. 5.6.10) *(not for 2.2M)
2 .. 8
0 (Master)
1 .. 7 (Slaves)
*(600 ..8300
RPM)
1200 .. 3000
RPM
Pump pressure
2
0
*(2800 RPM)
2920 RPM
Keyboard
Keyboard
P.I.D. factors
K
proportional
K
integral
K
derivative
Pressure ramp
1. K
proportional
: Pressure error
multiplayer
2. K
integral
: Integral of pressure
error multiplier
3. K
derivative
(not for 2.2M)
4.
Pressure ramp [bar/s]
1 .. 100
1 .. 100
0 .. 100
*(0.01..4.99
bar/s)
0.1 .. 10.0 bar/s
25
25
25
P. Absolute:
*(0.5 bar/s)
0.25 bar/s
Differential:
*(0.10 bar/s)
0.5 bar/s
Alarm history
Alarm N°
Type
Visualization of last 100 alarm in
chronologic order (see table 12
and 13)
Table 11: advanced functions sub-menu
*(…) only for parmeters IMTP(D)/ITTP(D)2.2M
6.4 Alarms
6.4.1 Alarm list for Inverter models IMTP(D)2.2M – ITTP(D)2.2M:
Alarm
Number
Alarm Type Description
1 Current Peak Immediately stop probably caused by short-circuit
Automatic re-start; final stop after 10 consecutive occurrences
2 Over-Voltage Normally caused by over voltage pick supply. Automatic re-start;
final stop after 10 consecutive occurrences
3 Inverter Temperature Over temperature IGBT protection (90°C)
Automatic re-start; final stop after 10 consecutive occurrences
