2010 dmm 72/96 599 73 68-54
12.2 Key to diagram
Appliance electrical components PCB components
1. Main circuit board
2. Door safety interlock (with light micro-switch)
2a Door safety interlock (without light micro-switch)
3. Electronic pressure switch
4. NTC (washing)
5. Flow sensor
6. Weight sensor
7. Pre-wash solenoid
8. Wash solenoid
9. Bleach solenoid valve
10. Hot water solenoid
11. Heating element
12. Display board
13. Motor control board (Inverter)
14. Triple-phase motor
15. Tachometric generator (motor)
16. Circulation pump
17. Aqua control sensor
18. Drain pump
19. Drum light
DRAIN_YTY Drain pump Triac
DOOR_TY Door interlock Triac
DOOR_CLOSE_TY Door interlock Triac
REC PUMP_TY Circulation pump TRIAC switch
PWELT_TY Pre-wash solenoid Triac
WELV_TY Wash solenoid Triac
BELT_TY Electronically controlled TRIAC bleach
valve
HELT_TY Hot water solenoid triac
K1 Heating element relay
K2 Heating element relay
