SERIES 9 if the two earth wires connecting the front panel have been
disconnected, reconnect them to the fastons of the control panel crosspiece.
13.2.5 Analogue pressure switch
Remove the worktop (see relevant paragraph).
Remove the connector.
Pull out the small tube which connects it to the pressure chamber.
Tighten the two tabs which secure it to the cabinet and remove it.
13.2.6 Detergent dispenser
Remove the worktop (see relevant paragraph).
Remove the control panel (see relevant paragraph).
Pull out the pipes that connect it to the solenoid valves (cold water and where
featured hot water)
Unfasten the two screws securing it to the central crosspiece.
Unfasten the screw in the clamp that fixes the detergent loading pipe to the tub
and remove it from its seat.
