Electrolux Compass Pro WS6-8 - Page 36

36
Installation manual
WS6–20
Electrical connections
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended
fuse
A
Electric heated 220-240V 1/1N~ 50/60 4.8/13.0 5.3/13.5 25/63
220-240V 3~ 50/60 4.8/13.0 5.3/13.5 16/35
380-415V 3N/3~ 50/60 4.8/13.0 5.3/13.5 10/25
440V 3~ 50/60 13.0 13.5 20
480V 3~ 60 13.0 13.7 20
Non heated/Steam heated 208-240V 1/1N~ 50/60
1
0.8 10
380-480V 1~
2
50/60
1
0.8 10
1. Total power and recommended fuse does not depend on the heating power in those cases.
2. Prepared for 3~
WS6–28
Electrical connections
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended
fuse
A
Electric heated 220-240V 3~ 50/60 18.0 18.8 50
380-415V 3N/3~ 50/60 18.0 18.8 32
440V 3~ 50/60 18.0 18.8 32
480V 3~ 60 18.0 18.8 25
Non heated/Steam heated 208-240V 1/1N~ 50/60
1
1.1 10
380-480V 1~
2
50/60
1
1.1 10
1. Total power and recommended fuse does not depend on the heating power in those cases.
2. Prepared for 3~
WS6–35
Electrical connections
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended
fuse
A
Electric heated 220-230V 3~ 50/60 19.1 20.2 63
220-240V 3~ 50/60 19.8/23.0 20.9/24.1 63/63
380-400V 3N/3~ 50/60 19.1 20.2 32
380-415V 3N/3~ 50/60 19.8/23.0 20.6/24.1 32/50
440V 3~ 50/60 21.0/23.0 22.2/24.1 32/35
480V 3~ 60 22.8/23.0 23.9/24.1 32/32
Non heated/Steam heated 208-240V 1/1N~ 50/60
1
1.3 10
380-480V 1~
2
50/60
1
1.3 10
1. Total power and recommended fuse does not depend on the heating power in those cases.
2. Prepared for 3~
