Parts List
7-11
Ref # Part # Description
3 216503100 Screen-drain
5 297259600 Fan Blade, evaporator
6 297200600 Breaker Kit w/corners, no lock slot
9 297200100 Breaker Kit w/corners, 32”, top and bottom
13 # 297250000 Motor, fan, 115 V
14 216822900 Switch, light/lamp, ramp
15A 297048600 Light Bulb/Lamp, short
16A 297139501 Socket, light/lamp, 25 W
19 216204902 Gasket-evap cover
25 297099254 Cover-evaporator
26 297091600 Case-crisper, shallow
26A 297091601 Case-crisper, deep
26B 297091800 Panel, crisper window
26C 297091703 Panel, crisper front
26E 297099400 Divider-crisper, shallow
26F 297099401 Divider-crisper, deep
26G 297123700 Case-deli
27A 240362201 Control-humidity
28 297179300 Hinge, bottom/RH
29 216313501 Hose-drain
32 5308005500 Drain
34A 297053102 Shield-light
34B 297053200 Lens, light
35 216273000 Clip, drain hose
37 297273900 Trim-cabinet corner, white, (2)
38 297283800 Hinge-upper
40 297164402 Cover-hinge, silver
41 240578902 Screw, hex head, 1/4-20 x 5/8
42 297108901 Shelf-sliding
47 297133000 Baffle-plate
47A 297102700 Insert-pan cover, glass
47B 297102701 Insert-pan cover, glass, lower
50 08013207 Bracket-fan motor
62 297142600 Screw, blunt, 8-32 x 5/8
63 216396900 Screw, leveling foot, plastic, adjustable
63* 297164650 Bracket, LH leg levelor
63* 297164651 Bracket, RH leg levelor
71A 297146800 Screw, 8-18AB x 0.470
72 297036900 Grille/Kickplate, 32”, white
93 5304460605 Screw, ph truss head, 8-18AB x 0.500
93A 297174300 Screw, #8, 18x.63, self pierce
* 216327800 Clip, wire
131 297130200 Channel-shelf mtg, side, (2)
148 297271700 Frame-crisper cover
148A 297271702 Frame-crisper cover, lower
152 216974600 Bearing, hinge closer
154 297053000 Wire, jumper
155 5303313703 Clip, (2)
169 216912401 Screw, hex washer head, 8-32 x 0.500, bracket fan mtr, (2)
170 297280400 Valve, breather
171 297092700 Bracket, crisper cover, RH
172
297092701 Bracket, crisper cover, LH
173 297107602 Slide, crisper, RH
174 297107603 Slide, crisper, LH
175 297099500 Support-crisper
177 297116000 Electronics, theater lgt
* 297001704 Insulation, 24”, drain tube
* 5303305324 Paint, touch-up, white
* 297226504 Energy Guide
# Functional Parts
* Non-Illustrated Parts
