Parts List
7-13
Ref # Part # Description
1 297152200 Condenser, dynamic
2 5308000110 Strap-evap/heater, aluminum, (2)
4 # 216938600 Drier-filter
5 # 297171500 Harness-main
14 # 216730700 Heater-defrost
15 # 216997300 Evaporator
15A 297319400 Heat Exchanger
15B 297114000 Light Bulb, short, blue tint, 40W
16 241507803 Socket-light
* 297108000 Jumper-wire, electronic w/lt
17 297110301 Box-control, front
17* 5304455649 Screw, pan hd, 6-20 x 0.438
18 297078701 Insulator-evap, styrofoam, RH
19 297078801 Insulator-evap, styrofoam, LH
20 216731001 Thermostat, defrost
27 297293300 Grommet, compressor
29 # 297270400 Compressor, w/o electricals
30 216954229 Controller, compressor
31 297165800 Pan-drain
32 216649200 Clip, controller
35 297177200 Bolt, compressor
43B 297315800 Clip, wire
55 # 218909912 Capacitor, run, 220 VAC, 12 microfarad
57 297110901 Overlay-control box
60 241584301 Motor-condenser fan
61 241639501 Blade-condenser fan
86 216036601 Screw, RWHD, 8-32A x 0.500, GX-CA
87 5304463290 Screw, hi-lo blunt, #8-18X1/2
93 5304460605 Screw, ph truss head, 8-18AB x 0.500
107 297165400 Shield, compressor, Compartment
130 216486800 Support, evaporator mtg
136 240405201 Grommet, rubber, black, cond tube/wire
137# 242007905 Filter, water, carbon cassette, front, with o’rings
138 240397301 Button-filter release
139 240396002 Base-water filter
141 297164200 Divider, air flow
141A 297194700 Divider, small, air flow
146 297164000 Shroud-fan orfice
146* 216337701 Screw, HWH, 10-24 x 0.500, Swage
151# 297334200 Electronic control, assy
153 297110200 Hose-junction attachment
154 297112901 Hose, water inlet
154* 297130900 Cap, hose attachment
155 241518001 Nut, 1/2-20, nylon, water hose, (2)
156 297110100 Retainer, hose junction
157 297110500 Raceway, water filter
158 297111000 Standoff
198 240397401 Retainer
199 240397501 Rod
199* 240398401 Spring-filter release rod
205 297108500 Cap-air filter
206 241504902 Filter-air
*
216502500 Sleeve, suction line
* 240555002 Screw-#8-32 X 3/8
* 297110400 Thermistor
* 297174300 Screw, #8, 18x.63, self pierce
* # 297169901 Cord-power, flat
# Functional Parts
* Non-Illustrated Parts
