Parts List
7-7
Ref # Part # Description
1 297044902 Tube-water inlet, inlet valve, to ice maker
1* 240561701 Seal-water inlet, inlet valve, to ice maker
2 5304456650 Spring-shutoff arm, ice maker
3 5304456657 Nameplate
4 5304456658 Gear
5 5304456659 Plate-mounting
6 5304456691 Screw, M 3x20 #3, valve plate
7 # 5304445222 Motor-ice maker Svo
7* 5304445223 Spring Beam
8 5304456661 Spacer-hold switch
9 5304456662 Cam
10 5304456689 Washer, nylon
11 # 5304456663 Thermal Cutoff, ice maker, complete assy
12 5304456664 Harness-wiring
13 5304456665 Thermostat, ice maker
14 5304455676 Screw, plask, 4x14x3/4
15 # 5304456667 Switch-micro, (3)
16 5304456668 Support
17 5304456669 Mold-ice maker, w/therm cut off
18 5304456670 Ejector-ice
18* 240352602 Wiring Harness, internal, wiring harness
19 5304456671 Bearing & Inlet, fill cup
20 5304455677 Screw, 8-32 x 3/8
21 5304456672 Ice Stripper
22 5304456673 Shut-off Arm
23 5304456674 Screw, M 4x25 #2, mold-to-support, (2)
24 5304456675 Lever Arm
25 5304456676 Screw, M 4x12.8 #2, lever arm/sprt
26 5304455680 Screw, plask, 4-14 x 3/8
27 5304456677 Screw, M 3x25 #3, hold switch mtg, (2)
28 5304456660 Screw, M 4x6 #2
29 5304456678 Screw, M 3x12 #3, (2)
30 5304456679 Screw-timing adj, M 4x25 #3
31 5304456680 Insulator
32 5304456681 Plate-valve switch
33 5304456682 Spring, timing adjust
34 5304456683 Screw, M 4x12 #2, (3)
35 5304456684 Screw
36 5304456685 Cover-ice maker
36* 5304456690 Label, ID plate
51 216887500 Tube, water, ice maker
55 # 241803701 Valve-water, single solenoid, 60 Hz, 105/120 V
60 218362501 Screw, hex washer head, 8-18AB x 1.250, spacer, (2)
61 5304456686 Bracket-leveling, ice maker
62 5304456687 Screw-IM brkt mtg, pan hd phillips, 8-32T x 0.375
65 240385201 Container, ice bin
* 241642503 Ice Maker, radius cube, 115 V, Svce
* 241642601 Harness-wiring Svo
* 241806601 Connector-water, straight
* 297114101 Adapter-water supply, nut & sleeve, compression ftg
* 5304456666 Screw, M 3x20 #2, (6)
* 5304456688 Terminal
* 5304456692 Washer
*
5304456693 Nut, M 3.5
* 5304456737 Washer
* IM501 Ice Maker Kit
# Functional Parts
* Non-Illustrated Parts
