Electrolux EFP 5519 - Characteristics

EN
2
8
28
CHARACTERISTICS
Dimensions
490 - 520
548 - 598
29-39 29-39
115
115
20-70
0-60
Components
Ref. Q.ty Product Components
1 1 Hood Body, complete with: Controls, Light, Blower,
Filters
8 1 Directional Air Outlet grille
9 1 Flange ø 150 mm
10 1 Damper ø 150
10a 1 Flange ø 120 mm
10b 1 Adapting ring ø 120-125 mm
20 1 Closing element of Plastic
21 1 Accessory Frontal
22 2 Closing element Metallic
Ref. Q.ty Installation Components
7.1a 2 Brackets 50x100x9 (EFP5525)
7.1b 2 Brackets 50x100x25 (EFP5525)
7.1c 2 Brackets 50x100x20 (EFP6529/EFP6519)
7.1d 2 Brackets 50x100x35 (EFP6529/EFP6519)
12a 7 Screws 3,5 x 16
12e 2 Screws 2,9 x 12,7
12f 11 Screws 2,9 x 9,5
Q.ty Documentation
1 Instruction Manual
12e
8
9
1
12a
20
12f
21
12a
7.1a
7.1b
7.1c
7.1d
12a
7.1a
7.1b
7.1c
7.1d
10a
10
10b
22
