3.1 ERF2600 Loads layout
AC In/Output
ERF Nomenclature
J1:1
Neutral
NEUTRAL
4 Pin
EPII 7.92
J1:2
Line In
IN_LIVE
J1:3
Line Out
LIVE
J1:4
STD Compressor
COMP_LIVE
J2:1
Main Water Valve
RELAY_7_LIVE
15W
6 Pin
EPII 3.96
J2:2
Cube Solenoid
RELAY_8_LIVE
48+/-25%
J2:3
FFIM Water Valve
SSR_1_LIVE
15W
J2:4
Disp Water Valve
SSR_3_LIVE
15W
J2:5
Empty
-
J2:6
Neutral
NEUTRAL
J3:1
FF Evap Heater
RELAY_6_LIVE
258W
9 Pin
EPII 3.96
J3:2
FZ Evap Heater
HEATER_LIVE
258W
J3:3
VCZ heater
RELAY_4_LIVE
20W
J3:4
IM Heater
RELAY_5_LIVE
70W
J3:5
Auger
RELAY_3_LIVE
100W
J3:6
Fill Heater
SSR_2_LIVE
2W
J3:7
Empty
-
J3:8
Neutral
NEUTRAL
J3:9
Neutral
NEUTRAL
DC In/Output
J8:1
VCZ Fan (OR FZ
Light)
12V
2W
12 pin
EP2.5
-
J8:2
DC_PWM_LO
AD_OUT_4
J8:3
VCC (Inverter
Signal)
12V_VSC
4W?
J8:4
VSC
J8:5
VCZ Damper
OUT1A
J8:6
OUT1B
J8:7
OUT2A
J8:8
OUT2B
J8:9
Stepper for
Cooling
OUT3A
J8:10
OUT3B
J8:11
OUT4A
J8:12
OUT4B
J7:1
Twist IM motor
CNT_MOT_3
4,2W
10 Pin
EP2.5
-
J7:2
CNT_MOT_4
J7:3
Twist IM motor
CNT_MOT_1
J7:4
CNT_MOT_2
J7:5
IM Mold NTC
5V
J7:6
NTC_6
J7:7
IM Bail Arm
5V
J7:8
BAIL
J7:9
VCZ Damper
Heater
12V_LOAD_5
1W
J7:10
DC_PWM_
LOAD_OUT_5
DC In/Output
J4:1
12V
12V
30W
3 Pin
EP2.5 -
J4:2
5V
5V
J4:3
GND
GND
30W
J6:1
FF LED
12V_LOAD_1
5,6W
14 Pin
EP2.5 -
J6:2
DC_PWM_LOAD_OUT_1
J6:3
IM Fan
12V_LOAD_2
2.4W
J6:4
(VCZ LED on UI)
DC_PWM_LOAD_OUT_2
J6:5
FF Fan
12V_LOAD_6
3W
J6:6
DC_PWM_LOAD_OUT_6
J6:7
GND
J6:8
FZ Fan
12V_LOAD_7
3W
J6:9
DC_PWM_LOAD_OUT_7
J6:10
GND
J6:11
Cond Fan
12V_LOAD_8
3W
J6:12
DC_PWM_LOAD_OUT_8
J6:13
GND
J6:14
VCZ Fan GND
GND
J9:1
FF Door SW
5V
10 pin
EP2.5 =
J9:2
DOOR_SW_1
J9:3
For Paddle SW
5V
J9:4
DOOR_SW_4
J9:5
FF NTC
5V
J9:6
NTC_1
J9:7
FF EVAP NTC
5V
J9:8
NTC_2
J9:9
Flip Mullion Heater
/Stepper Valve
12V_LOAD_3
8W+
6W
J9:10
DC_PWM_LOAD
_OUT_3
