0308 24
7
Notice
Date Page
05102004
INSTALLATION
MANUAL
Electric, steam heating specications
Fan maximum ow rate with no pressure : 880 Pa.
Average temperature of exhaust at the machine outlet :
- electric heating : 65°C (150°C)
- steam heating : 65°C (150°C)
Gas heating specications
Fan maximum ow rate with no pressure : 880 Pa.
Average temperature of exhaust at the machine outlet : 110°C (212°C).
For gas heating, the required combustion fresh air supply should be not less than 2 m³/h (1.17
cfm) per kW :
- either 78 m³/h (46 cfm) for a 1.90 m (75") machine
- or 104 m³/h (61 cfm) for a 2.50 m (98") machine
- or 130 m³/h (77 cfm) for a 3.20 m (126") machine
Values of the adjustment of safety pressure switch :
- either 147 Pa (15 mmH
2
O) for a 1.90 m (75") machine
- or 88 Pa (9 mmH
2
O) for a 2.50 m (98") machine
- or 49 Pa (5 mmH
2
O) for a 3.20 m (126") machine
NOTE : if the ow is insufcient due to an excessive head loss, a safety pressure switch
will automatically switch the heating off.
7. Installation
