0608 2
7
D1670
D0466
A
B
Notice
Date Page
05102004
INSTALLATION
MANUAL
7. Installation
Remove of the transport locks tted
CAUTION
Before putting the machine into service, it is compulsory to remove
the 2 transport locks tted.
To do so, remove the xing screws of the
transportation bridles (A).
Keep the transport locks tted with their
screws and bolts to be able to assemble
them again in case you would need to lift the
machine.
Nota : Never handling the machine
without the transportation bridles.
Transport angles :
Screw off the screws to remove the red
transport angles (B) with a key.
CAUTION : Do not remove this screws.
Keep this angles to eventually lift the ma-
chine.
Block the screws which maintained this
angles.
To Next Page
